1997 2000 California EV (v11 EV Usa) 1100 Front Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 03434300 | FRT FNDR BARE C (#03434300) |
| 1 | 03434301 | FRT FNDR ORG/BR D (#03434301) |
| 1 | 03434302 | LT BLUE/ BLK (#03434302) |
| 1 | 03434303 | FRT FNDR RED/WH D (#03434303) |
| 1 | 03434304 | EV FRT FENDER (#03434304) |
| 1 | 03434305 | FRT FNDR GRY/BL D (#03434305) |
| 1 | 03434306 | Front mudguard (#03434306) |
| 1 | 03434307 | Front mudguard (#03434307) |
| 1 | 89000347 | FRT FNDR CHERRY RED AND WHITE (#89000347) |
| 2 | 03435200 | MLDG RH FRT A (#03435200) |
| 3 | 03435400 | MLDG LH FRT A (#03435400) |
| 4 | 39922200 | PLATE (#39922200) |
| 5 | 03435300 | MLDG RH REAR (#03435300) |
| 6 | 03435500 | MLDG LH REAR (#03435500) |
| 7 | 03436400 | MOUNTING BLOCK (#03436400) |
| 8 | 03436500 | EYELET (#03436500) |
| 9 | 03436300 | PLATE (#03436300) |
| 10 | 98052225 | BOLT (#98052225) |
| 11 | 92781053 | LOCK NUT (#92781053) |
| 12 | 03436600 | FORK BRACE (#03436600) |
| 13 | 98230851 | ALLEN BOLT (#98230851) |
| 14 | 14615901 | WASHER (#14615901) |
| 15 | 98230622 | ALLEN SCREW (#98230622) |
| 16 | 66478610 | WASHER (#66478610) |
| 17 | 30576100 | BUSHING (#30576100) |
| 18 | 91551010 | GROMMET (#91551010) |
| 19 | 03437001 | REAR FNDR ORG/B D (#03437001) |
| 19 | 03437002 | REARFNDR BLU/BL D (#03437002) |
| 19 | 03437003 | REARFNDR RED/WH D (#03437003) |
| 19 | 03437004 | REARFNDR BLK/GR D (#03437004) |
| 19 | 03437005 | REAR FENDER 1100EV (#03437005) |
| 19 | 03437006 | Rear mudguard (#03437006) |
| 19 | 03437007 | Rear mudguard (#03437007) |
| 19 | 304370602 | REAR FENDER (#304370602) |
| 19 | 89000348 | REAR FNDR CHERRY RED/WHITE (#89000348) |
| 20 | 91551099 | RUBBER (#91551099) |
| 21 | 03439000 | SCREW (#03439000) |
