1997 2000 California EV (v11 EV Usa) 1100 Rear Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 03630601001 | Rear wheel (#03630601001) |
| 2 | 03617700 | TIRE VALVE A (#03617700) |
| 3 | 92204220 | BEARING (#92204220) |
| 4 | 14634051 | SPACER (#14634051) |
| 5 | 03631100 | SPOKE 112MM (#03631100) |
| 6 | 03631000 | SPOKE 164MM (#03631000) |
| 7 | 03631400 | SPOKE 170MM(#03631400) |
| 8 | 03611700 | SPOKE NIPPLE (#03611700) |
| 9 | 01635700 | REAR BRAKE ROTOR - BLACK (#01635700) |
| 9 | 03635700 | REAR BRAKE DISCO DISCO FRENO POST. ORO (#03635700) USE 01635700 |
| 10 | 30611460 | ALLEN BOLT (#30611460) |
| 11 | 03633300 | AXLE - REAR (#03633300) |
| 12 | 01336800 | RUBBER BLOCK (#01336800) |
| 13 | 90706490 | O RING (#90706490) |
| 14 | 30335260 | DISC-CUSH DRIVE B (#30335260) |
| 15 | 14335303 | RING (#14335303) |
| 16 | 17335950 | LOCK PLATE (#17335950) |
| 17 | 61013800 | SPRING WASHER (#61013800) |
| 18 | 98054312 | BOLT (#98054312) |
| 19 | 30634160 | SPACER A (#30634160) |
| 20 | 14634400 | RING (#14634400) |
| 21 | 29616450 | NUT A (#29616450) |
| 22 | 14616150 | WEIGHTS (#14616150) |
| 23 | 03339800 | REAR WHEEL FLANGE (#03339800) |
