1998 2001 Nevada Club 750 Front Rear Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 314344651 | #01 Front mud'ard, white (#314344651) |
| 1 | 89000213 | Front mudguard, black (#89000213) |
| 1 | 89000317 | Front mudguard, white (#89000317) |
| 1 | 89000318 | Front mudguard, red (#89000318) |
| 1 | 89000319 | Front mudguard blu (#89000319) |
| 1 | 89000320 | Front mudguard, black (#89000320) |
| 2 | 31436665 | #02 Stabilization plate (#31436665) |
| 3 | 98230826 | BOLT (#98230826) |
| 4 | 90706092 | O RING (#90706092) |
| 5 | 91180829 | #05 Spacer (#91180829) |
| 6 | 13436561 | CABLE HOLDER (#13436561) |
| 6 | 28659740 | GROMMET (#28659740) |
| 7 | 92630206 | NUT (#92630206) |
| 8 | 31439565 | SCREW (#31439565) |
| 9 | 31437073 | Rear mudguard blank (#31437073) |
| 9 | 31437074 | #04 Rear mudguard blank (#31437074) |
| 9 | 89000216 | Rear mudguard, black (#89000216) |
| 9 | 89000321 | Rear mudguard, white (#89000321) |
| 9 | 89000322 | Rear mudguard, red (#89000322) |
| 9 | 89000323 | Rear mudguard, blue (#89000323) |
| 9 | 89000324 | Rear mudguard, black (#89000324) |
| 9 | 89000376 | Rear mudguard, white (#89000376) |
| 9 | 89000377 | Rear mudguard, red (#89000377) |
| 9 | 89000378 | Rear mudguard, blue (#89000378) |
| 9 | 89000379 | Rear mudguard, black (#89000379) |
| 10 | 31439160 | #10 Rear mud'ard supp. (#31439160) |
| 11 | 98054320 | BOLT (#98054320) |
| 12 | 95000206 | WASHER (#95000206) |
| 13 | 93110060 | RUBBER WASHER (#93110060) |
| 14 | 95100141 | WASHER (#95100141) |
