1998 2002 Quota ES 1100 Dashboard
| Position | Part Number | Description |
|---|---|---|
| - | 30766226 | #01 Dashboard panel (#30766226) |
| 2 | 98370616 | BOLT (#98370616) |
| 3 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 4 | 91180607 | SPACER (#91180607) |
| 5 | 30761525 | SPEEDOMETER KPH C (#30761525) |
| 5 | 30762425 | #05 Speedometer (#30762425) |
| 6 | 29767860 | Speedo, and tach bracket (#29767860) |
| 7 | 02767200 | TACHOMETER WHITE FACE (#02767200) |
| 7 | 30767225 | TACHOMETER (#30767225) |
| 8 | 17768360 | SPEEDO DRIVE GEAR 1185000 (#17768360) |
| 9 | 28760410 | CABLE SPEEDO (#28760410) |
| 10 | ||
| 11 | 12763300 | SPEEDOMETER DRIVE GEAR (#12763300) |
| 12 | ||
| 13 | 30764125 | PLATE (#30764125) |
| 13 | 30764126 | SUPPORT PLATE (#30764126) |
| 14 | 98230515 | ALLEN SCREW (#98230515) USE 98370515 |
| 15 | 30758325 | LAMP HOLDER (#30758325) |
| 16 | 30758125 | LAMP HOLDER (#30758125) |
| 17 | 30758025 | LAMP HOLDER (#30758025) |
| 18 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 19 | 02768600 | LAMP HOLDER (#02768600) |
| 20 | 30763825 | BRACKET A (#30763825) |
| 21 | 98250535 | SCREW (#98250535) |
| 22 | 92660005 | Flanged nut (#92660005) |
| 23 | 92602205 | NUT (#92602205) |
| 24 | 01782500 | IGNITION SWITCH (#01782500) |
| 25 | 97260425 | SHEAR BOLT (#97260425) |
| 26 | 30783630 | IGN. SWITCH COVER (#30783630) |
| 27 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 28 | 30736825 | COMBINED UNIT C (#30736825) |
| 29 | 93450119 | BULB 12V (#93450119) USE 163015 |
