1998 2002 Quota ES 1100 Front Fork Km112000
| Position | Part Number | Description |
|---|---|---|
| 1 | 30530560 | Piston (#30530560) |
| 2 | 27530511 | LOCK NUT (#27530511) |
| 3 | 03530511 | CIRCLIP A (#03530511) |
| 4 | 03530506 | SCREW W/SEAL A (#03530506) |
| 5 | 30504526 | Plug (#30504526) |
| 5 | 30504527 | Plug (#30504527) |
| 5 | 30530561 | O RING (#30530561) USE AP8163104 |
| 6 | 30530562 | #06 Screw (#30530562) |
| 7 | 30530563 | #07 Spring seat (#30530563) |
| 8 | 30526626 | Spring (#30526626) |
| 9 | 30530564 | Pipe (#30530564) |
| 10 | 30525426 | Sleeve (#30525426) |
| 11 | ||
| 12 | 30530565 | RH rod (#30530565) |
| 13 | 30530566 | LH rod (#30530566) |
| 14 | 01530572 | NUT (#01530572) |
| 15 | 30522526 | #15 LH sleeve cpl. (#30522526) |
| 16 | 30522626 | #16 RH sleeve cpl. (#30522626) |
| 19 | 01530580 | Ring (#01530580) |
| 28 | 30526326 | RH stroke limit stop (#30526326) |
| 28 | 30526327 | LH stroke limit stop (#30526327) |
| 29 | 03530522 | O RING (#03530522) |
| 30 | 30530567 | Support plate valve (#30530567) |
| 31 | 03530524 | DUST SEAL (#03530524) for Fork seal/dust cover use 03530000 |
| 32 | 03530525 | CIRCLIP (#03530525) |
| 33 | 03530526 | FORK SEAL (#03530526) Fork seal/dust cover kit use 03530000. |
| 34 | 03530527 | SPACER A (#03530527) |
| 35 | 03530528 | BUSHING-UPPER (#03530528) USE AP8163093 |
| 38 | 30530568 | #38 Washer (#30530568) |
| 39 | 30530569 | Screw (#30530569) |
| 40 | 30530572 | #40 O-ring (#30530572) |
| 42 | 30530574 | Shock Absorber (#30530574) |
| 43 | 30530575 | Shock absorber (#30530575) |
| 44 | 30526426 | LH plunger, complete (#30526426) |
| 45 | 30526427 | RH plunger, complete (#30526427) |
| 46 | 03530508 | CUP A (#03530508) |
| 47 | 30500230 | LOWER H/BAR CLAMP (#30500230) |
| 48 | 30500630 | UPPER H-BAR CLAMP (#30500630) |
| 49 | 30530576 | Screw (#30530576) |
| 50 | 66530505 | ALLEN BOLT (#66530505) USE 98682430 |
| 51 | 98620365 | SCREW (#98620365) |
| 52 | 30494026 | Lower plate (#30494026) |
| 53 | 27530506 | NUT (#27530506) |
| 54 | 27530505 | WASHER (#27530505) USE AP8123511 |
| 55 | 27530503 | RUBBER SLEEVE A (#27530503) |
| 56 | 27530504 | TUBE (#27530504) |
| 57 | 30493126 | Fork upper plate (#30493126) |
| 58 | 98622435 | ALLEN BOLT (#98622435) |
| 59 | 27530510 | WASHER (#27530510) |
| 60 | 30512830 | NUT (#30512830) |
| 61 | 30530577 | Adjuster screw (#30530577) |
| 62 | 30490226 | #62 Front fork (#30490226) |
