1999 2000 California Special 1100 Frame Frame
| Position | Part Number | Description |
|---|---|---|
| - | 30479560 | TOOL TRAY (#30479560) |
| - | 30909961 | TOOL KIT (#30909961) |
| 1 | 03400102 | FRAME - BARE E (#03400102) |
| 2 | 93180216 | RUBBER PLUG (#93180216) |
| 3 | 30450260 | ENGINE GUARD CRASH BAR FRONT EV, EV TOURING, STONE (#30450260) |
| 4 | 98621650 | SCREW (#98621650) |
| 5 | 91181210 | SPACER (#91181210) |
| 6 | 95021112 | WASHER (#95021112) USE 95022112 |
| 7 | 92602312 | NUT (#92602312) |
| 8 | 98230845 | ALLEN BOLT (#98230845) |
| 9 | 61270300 | WASHER (#61270300) |
| 10 | 98623635 | SCREW USE 9881 3635 (#98623635) |
| 11 | 17451750 | PLATE (#17451750) |
| 12 | 03469200 | SPACER LH A (#03469200) |
| 13 | 92660601 | CAGE NUT (#92660601) |
| 14 | 39103400 | RUBBER PAD FOR GAS TANK (#39103400) |
| 15 | 98822316 | ALLEN BOLT (#98822316) |
| 16 | 39103500 | PLATE (#39103500) |
| 17 | 00823931080 | PVC GASKET (#00823931080) |
| 18 | 61013800 | SPRING WASHER (#61013800) |
| 19 | 92602208 | NUT (#92602208) |
| 20 | ||
| 21 | 30461360 | BRACKET (#30461360) use 304613605 |
| 22 | 98230816 | SCREW (#98230816) |
| 24 | 30462360 | BRACKET (#30462360) |
| 25 | 30462060 | SEAT LOCK ASSY (#30462060) |
| 26 | 03469201 | SPACER RH (#03469201) |
| 27 | 30466860 | HELMET LOCK A (#30466860) |
| 28 | 19705900 | PLUG (#19705900) |
| 29 | 98230612 | ALLEN SCREW (#98230612) |
| 30 | 93180080 | PLUG (#93180080) |
| 31 | 30462160 | CABLE-SEAT LOCK (#30462160) |
| 32 | 95522508 | SPRING PIN (#95522508) |
| 33 | 30463260 | BRACKET A (#30463260) |
| 34 | 66468115 | SECURITY BOLT (#66468115) |
| 35 | 29418360 | BATTERY PLATE (#29418360) |
| 36 | 98054416 | BOLT (#98054416) |
| 37 | 95004208 | WASHER (#95004208) |
| 38 | 98622420 | ALLEN BOLT A (#98622420) |
| 39 | 92630508 | NUT (#92630508) |
| 40 | 03909900 | Toolkit (#03909900) |
| 41 | 03900030 | O MANL BASSA & CALIFORNIA SPECIAL (#03900030) |
