| Position |
Part Number |
Description |
| 1 |
03460530
|
FRONT SEAT (#03460530) |
| 2 |
03464030
|
REAR SEAT (#03464030) |
| 3 |
92602206
|
NUT (#92602206) USE STHN6MM |
| 4 |
03467330
|
PANEL RH PRIMER A (#03467330) |
| 4 |
03467331
|
PANEL RH BLACK B (#03467331) |
| 4 |
03467332
|
PANEL RH PEARL B (#03467332) |
| 4 |
03467333
|
PANEL RH GOLD/B B (#03467333) |
| 4 |
03467334
|
PANEL RH BLUE (NLA) (#03467334) |
| 4 |
89000342
|
RH SIDE COVER YELLOW (#89000342) |
| 5 |
03558130
|
SHOCK COVER RH (#03558130) |
| 6 |
03466930
|
PANEL LH PRIMER A (#03466930) |
| 6 |
03466931
|
PANEL LH BLACK (#03466931) |
| 6 |
03466932
|
PANEL LH PEARL B (#03466932) |
| 6 |
03466933
|
PANEL LH GOLD/B B (#03466933) |
| 6 |
03466934
|
PANEL LH BLUE (#03466934) |
| 6 |
89000343
|
LH SIDE COVER YELLOW (#89000343) |
| 7 |
03558230
|
SHOCK COVER LH (#03558230) |
| 8 |
03922230
|
PUSH CLIP (#03922230) |
| 8 |
03922231
|
CLIP (#03922231) |
| 9 |
00155930053
|
Gasket (#00155930053) |
| 10 |
98220830
|
SCREW A (#98220830) |
| 11 |
03459330
|
SPACER-UPPER (#03459330) |
| 12 |
91551165
|
GROMMET (#91551165) |
| 13 |
98220625
|
BOLT A (#98220625) |
| 14 |
03459331
|
SPACER A (#03459331) |
| 15 |
91551010
|
GROMMET (#91551010) |
| 16 |
03476230
|
COVER RH PRIMER B (#03476230) |
| 16 |
03476231
|
COVER RH BLACK SPECIAL (#03476231) |
| 16 |
03476232
|
COVER RH WHITE SPECIAL NLA (#03476232) |
| 16 |
03476233
|
RH side panel, brown (#03476233) |
| 16 |
03476234
|
R.H. SIDE COVER SILVER-BLU (#03476234) |
| 16 |
03476236
|
COVER RH BLACK C (#03476236) |
| 16 |
03476237
|
COVER RH PEARL C (#03476237) |
| 16 |
03476238
|
COVER RH BROWN C (#03476238) |
| 16 |
03476239
|
COVER RH BLUE C (#03476239) |
| 16 |
89000338
|
BATTERY COVER RH YELLOW (#89000338) |
| 16 |
89000360
|
BATT CVR RH YELLOW USA (#89000360) |
| 17 |
| 18 |
03476530
|
GUARD RH BARE (NLA) (#03476630) (#03476530) |
| 20 |
03476330
|
SIDE COVER LH (#03476330) |
| 20 |
03476331
|
COVER LH BLACK SPECIAL (#03476331) |
| 20 |
03476332
|
COVER LH WHITE SPECIAL (#03476332) |
| 20 |
03476333
|
LH side panel, brown (#03476333) |
| 20 |
03476334
|
LH side panel,navy blue/silver (#03476334) |
| 20 |
03476336
|
COVER LH BLACK (#03476336) |
| 20 |
03476337
|
COVER LH PEARL C (#03476337) |
| 20 |
03476338
|
COVER LH BROWN C (#03476338) |
| 20 |
03476339
|
COVER LH BLUE C (#03476339) |
| 20 |
89000339
|
BATTERY COVER LH YELLOW (#89000339) |
| 20 |
89000361
|
#20 LH side panel, yellow (#89000361) |
| 21 |
03922030
|
DECAL CA SPECIAL SILVER W/BLACK OUTLINE (#03922030) |
| 21 |
03922031
|
DECAL BASSA USA A (#03922031) |
| 22 |
03476630
|
GUARD LH A (#03476630) |
| 23 |
03478230
|
MOUNT LH (#03478230) |
| 24 |
03478331
|
PLATE LH A (#03478331) |
| 25 |
98230620
|
ALLEN BOLT (#98230620) |
| 26 |
95008206
|
WASHER (#95008206) |
| 27 |
92660601
|
CAGE NUT (#92660601) |
| 28 |
03478330
|
PLATE RH A (#03478330) |
| 29 |
02573900
|
GROMMET (#02573900) |
| 30 |
03478130
|
MOUNT RH (#03478130) |
| 31 |
98230610
|
SCREW (#98230610) |
| 32 |
03945400
|
DECAL-FUSEBOX (#03945400) |
