1999 2001 V 11 Sport mandello 1100 Dashboard
| Position | Part Number | Description |
|---|---|---|
| 1 | 02761500 | SPEEDO ASSY (#02761500) |
| 1 | 02762400 | SPEEDOMETER VEGLIA BRAND WHITE FACE (#02762400) |
| 2 | 23768310 | ANGLE DRIVE (#23768310) |
| 3 | 02762800 | TRIP RESET KNOB (#02762800) |
| 4 | 01760430 | SPEEDO CABLE (#01760430) |
| 5 | 04762500 | SPEEDO DRIVE (#04762500) |
| 6 | 04768300 | SPEEDO DRIVE (#04768300) |
| 7 | 01760030 | Dashboard complete (#01760030) |
| 7 | 01760040 | Dashboard complete (#01760040) |
| 8 | 93450120 | BULB ALL GLASS (#93450120) |
| 9 | 02767200 | TACHOMETER WHITE FACE (#02767200) |
| 10 | 01763030 | INSTR. CVR SPACER (#01763030) |
| 11 | 95100055 | WASHER (#95100055) |
| 12 | 01764040 | Carb. support base (#01764040) |
| 12 | 01764055 | INSTRUMENT HOLDER. (#01764055) |
| 12 | 02764000 | BRACKET (#02764000) |
| 13 | 02762301 | SPEEDO/TAC RUBBER GASKET (#02762301) |
| 14 | 01762031 | INSTRUMENT HOUSING DASH (#01762031) |
| 15 | 92781055 | Nut (#92781055) |
| 16 | 17762200 | RUBBER BOOT (#17762200) |
| 17 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 18 | 01766030 | Dashboard support, grey (#01766030) |
| 18 | 01766040 | SOCKET PANEL BLACK (#01766040) |
| 18 | 01766065 | MOUNT PLATE (#01766065) |
| 18 | 02766000 | GAUGE MOUNT A (#02766000) |
| 19 | 02765500 | PANEL RUBBER (#02765500) |
| 19 | 93222021 | Silentblock (#93222021) USE 93222023 |
| 20 | 91180721 | BUSHING (#91180721) |
| 21 | 98230636 | ALLEN BOLT (#98230636) |
| 21 | 98370609 | BOLT (#98370609) |
| 22 | 95100124 | WASHER (#95100124) |
| 23 | 92630206 | NUT (#92630206) |
| 23 | 92650106 | Flanged nut (#92650106) |
| 24 | 98622316 | SCREW (#98622316) |
| 24 | 98682312 | Screw, 6x12mm (#98682312) |
| 25 | 95004206 | WASHER (#95004206) |
| 25 | 95008306 | WASHER (#95008306) |
| 26 | 01766230 | Lamp-holding cover gray (#01766230) |
| 26 | 01766240 | LAMP HOLDING COVER BLK NLA (#01766240) |
| 27 | 98872115 | ALLEN BOLT (#98872115) |
| 28 | 02768200 | GSKT (#02768200) |
| 29 | 02768400 | PROTECTION-DASH (#02768400) |
| 30 | 02781100 | PANEL (#02781100) |
| 31 | ||
| 32 | 30577800 | NYLON WASHER (#30577800) |
| 33 | 01736830 | LOCKS KIT (#01736830) |
| 34 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 35 | 02768600 | LAMP HOLDER (#02768600) |
| 36 | 01782500 | IGNITION SWITCH (#01782500) |
| 37 | 97260415 | SECURITY BOLT A (#97260415) |
| 38 | 01747230 | INSTR. HARNESS (#01747230) |
