1999 2001 V 11 Sport mandello 1100 Foot Rests Lateral Stand
| Position | Part Number | Description |
|---|---|---|
| 1 | 02432100 | SIDE STAND B (#02432100) |
| 2 | 01433400 | SIDE STAND MOUNT B (#01433400) |
| 3 | 30432801 | SCREW (#30432801) |
| 4 | 95021114 | LOCK WASHER (#95021114) |
| 5 | 01433201 | PIVOT PIN (#01433201) |
| 6 | 01432730 | SPRING BRACKET (#01432730) |
| 7 | 30434001 | SPRING (#30434001) |
| 8 | 95100120 | WASHER (#95100120) use 95105320 |
| 9 | 30434000 | SPRING, SIDE STAND (#30434000) |
| 10 | 01433600 | PLATE A (#01433600) |
| 11 | 93242015 | V-11 SPORT SIDE STAND RUBBER (#93242015) |
| 12 | 30442705 | FOOTREST BRACKET RH (#30442705) |
| 13 | 98251040 | SCREW (#98251040) |
| 14 | 92630510 | NUT (#92630510) |
| 15 | 30440705 | FOOTREST RH FRONT (#30440705) |
| 16 | 30441805 | FOOTREST (#30441805) |
| 17 | 30441005 | FOOTREST PIN (#30441005) |
| 18 | 30441105 | SPRING (#30441105) |
| 19 | 30442205 | FOOTREST PIN A (#30442205) |
| 20 | 90280006 | E CLIP (#90280006) USE 005965 |
| 21 | 01444630 | RH BRACKET (#01444630) |
| 21 | 01444640 | BRACKET RH BLACK (#01444640) |
| 22 | 01444730 | LH MUFFLER BRACKET (#01444730) |
| 22 | 01444740 | BRACKET LH BLACK (#01444740) |
| 23 | 30442405 | FOOTREST RH REAR (#30442405) |
| 24 | 30442805 | FOOTREST L/H REAR (#30442805) |
| 25 | 30443105 | STOP PLATE (#30443105) |
| 26 | 94321062 | SPRING (#94321062) |
| 27 | 92295706 | BALL (#92295706) |
| 28 | 30441605 | FOOTREST SHIM (#30441605) |
| 29 | 92660310 | NUT A (#92660310) |
| 30 | 30433800 | TUBE (#30433800) |
| 31 | 01431930 | SIDE STAND LEVER (#01431930) |
| 32 | 98230618 | ALLEN BOLT A (#98230618) |
| 33 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 34 | 97040220 | ADJUSTER A (#97040220) |
| 35 | 92602205 | NUT (#92602205) |
| 36 | 02433800 | MOUNT PLATE A (#02433800) |
| 37 | 01759130 | SWITCH (#01759130) |
| 38 | ||
| 39 | 01431830 | SIDE STAND FLANGE (#01431830) |
| 40 | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 41 | 95000206 | WASHER (#95000206) |
| 42 | 91180604 | SPACER (#91180604) |
| 43 | 14615901 | WASHER (#14615901) |
| 44 | 98812425 | BOLT-BLACK (#98812425) |
