1999 2001 V 11 Sport mandello 1100 Fuel Tank
| Position | Part Number | Description |
|---|---|---|
| 1 | 01100230 | GAS TANK BARE (#01100230) |
| 1 | ||
| 1 | 01100233 | GAS TANK SILVER (#01100233) |
| 1 | 01100234 | FUEL-TANK BLACK GLOSS (#01100234) |
| 1 | 01100240 | FUEL-TANK RED (#01100240) |
| 2 | 02102400 | #02 Gasket (#02102400) |
| 3 | 02102300 | FLANGE (#02102300) |
| 4 | 01101700 | GAS CAP GASKET (#01101700) |
| 5 | 01103920 | FUEL FILLER CAP B (#01103920) USE 01103960 |
| 6 | 98620230 | SCREW (#98620230) |
| 7 | 98622210 | SCREW (#98622210) |
| 8 | 98622216 | ALLEN BOLT (#98622216) |
| 9 | 01917800 | DECAL RH A (#01917800) |
| 9 | 01917840 | MOTO GUZZI DECAL RH (#01917840) |
| 10 | 01917900 | DECAL LH (#01917900) |
| 10 | 01917940 | MOTO GUZZI DECAL LH (#01917940) |
| 11 | 01103030 | LEVEL SENDER (#01103030) |
| 12 | 01101830 | FUEL TAP FLANGE (#01101830) |
| 13 | 29217960 | WASHER (#29217960) |
| 14 | 98230510 | ALLEN BOLT (#98230510) |
| 15 | 01105330 | ELECTRIC VALVE FUEL TAP FIRST SERIES 90 DEGREE (#01105330) |
| 16 | 01104030 | V11 SPORT TANK PROTECTOR (#01104030) |
| 17 | 90706116 | O RING (#90706116) |
| 18 | 66103415 | RUBBER MOUNT (#66103415) |
| 19 | 14615901 | WASHER (#14615901) |
| 20 | 98622420 | ALLEN BOLT A (#98622420) |
| 21 | 98052445 | BOLT (#98052445) |
| 22 | 95100239 | WASHER (#95100239) |
| 23 | 02107100 | TANK GROMMET (#02107100) |
| 24 | 91180831 | Spacer, 8.4x12x21 (#91180831) |
| 25 | 01576530 | Nut with Clip (#01576530) |
| 26 | 02103600 | FUEL TANK PLATE (#02103600) |
| 27 | 02573900 | GROMMET (#02573900) |
| 28 | 98230515 | ALLEN SCREW (#98230515) USE 98370515 |
| 30 | 02101800 | FLANGE A (#02101800) |
| 31 | 03105300 | PETCOCK-ELECTRIC 60 DEGREES (#03105300) |
| 32 | 01736830 | LOCKS KIT (#01736830) |
| 33 | 00823944050 | HOSE (#00823944050) |
| 34 | 30103730 | UNION (#30103730) |
| 35 | 30104630 | GASKET (#30104630) |
| 36 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 37 | 01923330 | Decal set (#01923330) |
| 37 | 01923332 | Decal set (#01923332) |
| 37 | 01923340 | DECAL KIT (#01923340) |
| 38 | 29995735 | DECAL UNLEADED A (#29995735) |
| 39 | 29105460 | CAL 3 PETCOCK 1100 SPORT (#29105460) |
