1999 2001 V 11 Sport mandello 1100 Oil Radiator
| Position | Part Number | Description |
|---|---|---|
| 1 | 01162030 | OIL COOLER (#01162030) |
| 2 | 01582630 | OIL COOLER SCREEN (#01582630) |
| 2 | 01582640 | GRILL SILVER (#01582640) |
| 3 | 01164231 | RH OIL COOLER BRACKET (#01164231) |
| 4 | 98230616 | SCREW (#98230616) |
| 5 | 91551132 | RUBBER MOUNT (#91551132) |
| 6 | 98230615 | ALLEN SCREW A (#98230615) |
| 7 | 95000206 | WASHER (#95000206) |
| 8 | 01164431 | OIL COOLER BRACKET LH (#01164431) |
| 9 | 01161630 | OIL PIPE (#01161630) |
| 10 | 95100116 | WASHER (#95100116) |
| 11 | 01161330 | REDUCER (#01161330) |
| 12 | 01154230 | GASKET (#01154230) |
| 13 | 01161730 | NUT (#01161730) |
| 14 | 01162330 | OIL COOLER HOSE (#01162330) |
