2001 2002 California Ev ev Touring 80 1100 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 98622430 | SCREW (#98622430) |
| 2 | 03500660 | UPPER H-HAR CLAMP (#03500660) |
| 3 | 98052560 | BOLT (#98052560) |
| 4 | 03500260 | HANDLEBAR CLAMP (#03500260) |
| 5 | 27530505 | WASHER (#27530505) USE AP8123511 |
| 6 | 27530503 | RUBBER SLEEVE A (#27530503) |
| 7 | 03493100 | FORK CROWN C (#03493100) |
| 8 | 03498100 | RING NUT A (#03498100) |
| 9 | 03530503 | SPACER A (#03530503) |
| 10 | 92630110 | NUT (#92630110) |
| 11 | 03494000 | FORK BASE C (#03494000) |
| 12 | 03530504 | SCREW A (#03530504) |
| 13 | 03530505 | KNOB RH (#03530505) |
| 14 | 03530506 | SCREW W/SEAL A (#03530506) |
| 15 | 03530507 | FORK PLUG ASSY B (#03530507) |
| 16 | 03530508 | CUP A (#03530508) |
| 17 | 03530509 | SPACER (#03530509) |
| 18 | 03526600 | FORK SPRING A (#03526600) |
| 19 | 03525400 | FORK TUBE C (#03525400) |
| 20 | ||
| 21 | 03530511 | CIRCLIP A (#03530511) |
| 22 | 03530512 | TUBE RH B (#03530512) |
| 23 | 03530513 | LOCK NUT A (#03530513) |
| 24 | 03530514 | RH shock absorber (# 03530514) (#03530514) |
| 25 | 03530515 | SPRING A (#03530515) |
| 27 | 03530516 | PLUNGER RH A (#03530516) |
| 28 | 03530517 | WIPER RH A (#03530517) |
| 29 | 03530519 | WASHER A (#03530519) |
| 30 | 03530520 | NUT A (#03530520) |
| 31 | 03530521 | VALVE ASSY LWR A (#03530521) |
| 32 | 03530522 | O RING (#03530522) |
| 33 | 03530523 | ADAPTER A (#03530523) |
| 34 | 03530524 | DUST SEAL (#03530524) for Fork seal/dust cover use 03530000 |
| 35 | 03530525 | CIRCLIP (#03530525) |
| 36 | 03530526 | FORK SEAL (#03530526) Fork seal/dust cover kit use 03530000. |
| 37 | 03530527 | SPACER A (#03530527) |
| 38 | 03530528 | BUSHING-UPPER (#03530528) USE AP8163093 |
| 39 | 03522501001 | RH sleeve (#03522501001) |
| 40 | 98620340 | SCREW (#98620340) |
| 41 | ||
| 42 | 03530530 | ALLEN BOLT (#03530530) |
| 43 | 03522601001 | LH SLEEVE (#03522601001) |
| 44 | 03530531 | KNOB LH (#03530531) |
| 45 | 03530532 | TUBE LH B (#03530532) |
| 46 | 03530533 | LH shock absorber(# 03530533) (#03530533) |
| 47 | 03530534 | SPACER A (#03530534) |
| 48 | 03530535 | WASHER 12MM A (#03530535) |
| 48 | 03530536 | WASHER 15MM A (#03530536) |
| 48 | 03530537 | WASHER 17MM A (#03530537) |
| 49 | 03530538 | NEEDLE VALVE LH (#03530538) |
| 50 | 03530539 | PLUNGER LH A (#03530539) |
| 51 | 03530540 | NUT A (#03530540) |
| 52 | 03490601 | RH FORK LEG COMPLETE (#03490601) |
| 53 | 03490701 | LH FORK LEG COMPLETE (#03490701) |
| 54 | 30530521 | DRAIN SCREW A (#30530521) |
| 55 | 30530561 | O RING (#30530561) USE AP8163104 |
| 56 | 23943410 | CHROME PLUG (#23943410) |
| 57 | 98230618 | ALLEN BOLT A (#98230618) |
| 58 | 95004206 | WASHER (#95004206) |
