2001 2002 California Ev ev Touring 80 1100 Headlight
| Position | Part Number | Description |
|---|---|---|
| 1 | 02740501 | HL ASSY (#02740501) |
| 1 | 02740505 | front headlight (#02740505) |
| 1 | 03740531 | HEADLAMP ASSY D (#03740531) |
| 2 | 02746900 | H/L HARNESS (#02746900) |
| 3 | 01756100 | CONNECTOR 4 WAY (#01756100) |
| 4 | 91551105 | GROMMET (#91551105) |
| 5 | 93450232 | CAL H/L BULB 60/55 (#93450232) USE 292723 |
| 6 | 01756220 | CONNECTOR 3 WAY (#01756220) |
| 7 | 93450119 | BULB 12V (#93450119) USE 163015 |
| 8 | 03496100 | H/L BRKT RH B (#03496100) |
| 8 | 03496130 | LAMP MOUNT RH (#03496130) |
| 9 | 14439800 | SPACER (#14439800) |
| 10 | 95008208 | WASHER (#95008208) |
| 11 | 03496200 | H/L BRKT LH (#03496200) |
| 11 | 03496230 | LAMP MOUNT LH B (#03496230) |
| 12 | 98692318 | ALLEN SCREW (#98692318) |
| 13 | 98064425 | BOLT (#98064425) |
| 14 | 03750600 | SIGNAL RH FRT A (#03750600) |
| 14 | ||
| 15 | 03750601 | FRT TURN SIGNAL EV LH (#03750601) |
| 15 | ||
| 16 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 17 | 31753765 | SIGNAL LENS AMBER (#31753765) USE AP8124111 |
| 18 | 98682314 | Screw (#98682314) |
| 19 | 31743765 | HORN HIGH A (#31743765) |
| 20 | 31743766 | HORN LOW A (#31743766) |
| 21 | 31744765 | HORN COVER A (#31744765) |
| 22 | 14781670 | REFLECTOR (#14781670) |
| 23 | 02740400 | OPTICAL GROUP CENTARO AND EV LENS, REFLECTOR, ETC. (#02740400) |
| 23 | 03740431 | OPTICAL FOR LH DRIVING (#03740431) use 29740500 |
| 24 | 02740458 | H/L BODY (#02740458) |
