2001 2002 California Ev ev Touring 80 1100 Luggage Rack
| Position | Part Number | Description |
|---|---|---|
| 1 | 03466511 | Parcel rack assy (#03466511) |
| 1 | 03466515 | BACKREST/RACK W/RED LTHR PAD (#03466515) |
| 2 | 03468010 | BACKREST PAD (#03468010) |
| 2 | 03468015 | CUSHION RED LTHR (#03468015) |
| 3 | 95008306 | WASHER (#95008306) |
| 4 | 92602206 | NUT (#92602206) USE STHN6MM |
| 5 | 61270300 | WASHER (#61270300) |
| 6 | 03468210 | REAR COVER (#03468210) |
| 6 | 03468215 | Cover (#03468215) |
| 7 | 03468100 | BACKREST PIVOT BOLT (#03468100) |
| 8 | 94321007 | SPRING (#94321007) |
| 9 | 92295708 | BALL (#92295708) |
| 10 | 98358318 | screw (#98358318) |
