2001 2002 V 11 Le Mans sport Naked 1100 Air Box
| Position | Part Number | Description |
|---|---|---|
| 1 | 01114031 | AIR BOX HOUSING (#01114031) |
| 2 | 30113600 | AIR FILTER (#30113600) |
| 3 | 37113405 | COVER (37113405) USE 0111 3490 (#37113405) |
| 4 | 37114806 | INTAKE COLLAR (#37114806) |
| 5 | 93305040 | Clamp, 40x60x8 (#93305040) |
| 6 | 01116730 | RH REAR BRKT (#01116730) |
| 7 | 01116731 | LH REAR BRKT (#01116731) |
| 8 | 01114130 | AIR BOX BRKT, FRONT (#01114130) |
| 9 | 28576592 | Nut w/ Clip, 6mm (#28576592) |
| 10 | 98106082 | SCREW (#98106082) |
| 11 | 98084330 | Screw (#98084330) |
| 12 | 98350312 | CLUTCH MOUNT SCREW (#98350312) |
| 13 | 98350210 | Screw (#98350210) |
| 14 | 95004206 | WASHER (#95004206) |
| 15 | 02116901 | AIR TUBE LH (#02116901) |
| 16 | 00823952080 | FUEL HOSE V11 SPORT (#00823952080) |
| 17 | 95990084 | BANJO BOLT (#95990084) |
| 18 | 01154230 | GASKET (#01154230) |
| 19 | 01114400 | INTAKE FUNNEL (#01114400) |
| 20 | 30107401 | BANJO FITTING (#30107401) |
| 21 | 93304390 | TIE WRAP (#93304390) |
