2001 2002 V 11 Le Mans sport Naked 1100 Exhaust Unit
| Position | Part Number | Description |
|---|---|---|
| 1 | 01120932 | EXH PIPE RH 2ND SERIES (#01120932) |
| 2 | 01120933 | EXH PIPE LH 2ND SERIES (#01120933) |
| 3 | 90718370 | EXHAUST GASKET (#90718370) |
| 4 | 98370835 | ALLEN BOLT (#98370835) |
| 5 | 01121030 | EXHAUST PIPE FLANGE (#01121030) |
| 6 | 14615901 | WASHER (#14615901) |
| 7 | 92787008 | NUT (#92787008) USE 860651 |
| 8 | 95005311 | WASHER (#95005311) |
| 9 | 98110007 | PLUG (#98110007) |
| 10 | 30109330 | COPPER WASHER (#30109330) |
| 11 | 01126930 | MUFFLER CLAMP (#01126930) |
| 12 | 01123930 | Expansion chamber (#01123930) |
| 13 | 01123830 | EXHAUST COLLECTOR BRACKET (#01123830) |
| 14 | 98084412 | Screw (#98084412) |
| 15 | 93233030 | VIBRATION DAMPER (#93233030) |
| 16 | 30126700 | SPACER-TEFLON A (#30126700) |
| 17 | 30126701 | SPACER-TEFLON A (#30126701) |
| 18 | 95100239 | WASHER (#95100239) |
| 19 | 98084430 | Screw, 8mmx30mm (#98084430) |
| 20 | 14103400 | TANK BUSHING (#14103400) |
| 21 | 01123430 | EXHAUST CLAMP (#01123430) |
| 22 | 98084422 | Screw, 8mmx22mm (#98084422) |
| 23 | 95005312 | Washer, 8.5x24x2 (#95005312) |
| 24 | 92650108 | Nut, 8mmx1.25 (#92650108) |
| 25 | 01123042 | RH MUFFLER CF SKIN (#01123042) |
| 25 | 01123060 | MUFFLER RH (#01123060) |
| 26 | 01122942 | LH MUFFLER CF SKIN (#01122942) |
| 26 | 01122960 | MUFFLER LH (#01122960) |
| 27 | 95187008 | LOCK PLATE (#95187008) USE 1461 5901 |
| 28 | 91180819 | Spacer, 8.5x12x16 (#91180819) |
