2001 2002 V 11 Le Mans sport Naked 1100 Le Mans Headlight
| Position | Part Number | Description |
|---|---|---|
| 1 | 01740560 | Headlight (#01740560) |
| 1 | 01740565 | HEADLIGHT O2+ LEMANS (#01740565) |
| 1 | 01740567 | Headlight (#01740567) |
| 2 | 01757660 | INSTR. HARNESS (#01757660) |
| 3 | 91180834 | SPACER LEMANS 02+ HEADLIGHT (#91180834) |
| 4 | 01577160 | BUSHING (#01577160) |
| 5 | 93450232 | CAL H/L BULB 60/55 (#93450232) USE 292723 |
| 6 | 98082440 | BOLT HEADLIGHT LEMANS 02+ (#98082440) |
| 7 | 93450105 | PARKING LIGHT BULB (#93450105) USE 292022 |
| 8 | 01578961 | H/LAMP GASKET (#01578961) |
| 9 | 01740367 | Headlight Adjusting Pin (#01740367) |
| 10 | 94321116 | SPRING (#94321116) |
| 11 | 98680475 | Screw, 8x75mm (#98680475) |
| 12 | 01578660 | FAIRING SUPPORT (#01578660) |
| 13 | 92630108 | NUT 8MM (#92630108) |
| 14 | 02750600 | V11 SPORT TURN SIGNAL (#02750600) |
| 15 | 02750601 | V11 SPORT TURNSIGNAL (#02750601) |
| 16 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 17 | 02753700 | TURN SIGNAL LENS AMBER (#02753700) |
| 18 | 98370621 | BOLT (#98370621) |
| 19 | 95100121 | WASHER (#95100121) |
| 20 | 31743765 | HORN HIGH A (#31743765) |
| 21 | 31743766 | HORN LOW A (#31743766) |
| 22 | 01740366 | Headlight Adjusting Washer (#01740366) |
| 23 | 01781600 | REFLECTOR AMBER USE 1478 1670 (#01781600) |
| 24 | 01574960 | PLATE (#01574960) |
| 25 | 92640106 | #10 Selflocking nut (#92640106) |
| 26 | 98622318 | SCREW (#98622318) |
| 27 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 28 | 95000206 | WASHER (#95000206) |
| 29 | 91180606 | Spacer (#91180606) |
| 30 | 92660501 | CAGE NUT (#92660501) |
