| Position |
Part Number |
Description |
| 1 |
31460584
|
#01 Driver saddle Nevada Base (#31460584) |
| 2 |
31464084
|
#02 Rear saddle Nevada Base (#31464084) |
| 3 |
93110082
|
RUBBER WASHER (#93110082) |
| 4 |
92630106
|
NUT USE 92630707 (#92630106) |
| 5 |
92630206
|
NUT (#92630206) |
| 6 |
31469081
|
#06 RH front protect chrome (#31469081) |
| 7 |
31469181
|
#07 LH front protect chrome (#31469181) |
| 8 |
98370825
|
Hex Socket Screw (#98370825) |
| 9 |
31469281
|
#09 Spacer (#31469281) |
| 10 |
90706092
|
O RING (#90706092) |
| 11 |
234762101
|
#16 RH side cover blank (#234762101) |
| 11 |
89000421
|
#11 Valve housing (#89000421) |
| 11 |
89000426
|
SIDE COVER (#89000426) USE 03941000 |
| 11 |
89000431
|
#11 RH side cover white (#89000431) |
| 11 |
89000436
|
#11 RH side cover black (#89000436) |
| 11 |
89000441
|
#11 RH side cover grey platinum (#89000441) |
| 12 |
314763621
|
#17 LH side cover blank (#314763621) |
| 12 |
89000422
|
#12 LH side cover grey berlin (#89000422) |
| 12 |
89000427
|
#12 LH side cover grey berlin (#89000427) |
| 12 |
89000432
|
#12 LH side cover white (#89000432) |
| 12 |
89000437
|
#12 LH side cover black (#89000437) |
| 12 |
89000442
|
#12 LH side cover grey platinum (#89000442) |
| 13 |
89000462
|
#13 LH sticker red/grey (#89000462) |
| 13 |
89000463
|
#13 LH stic.blue/grey (#89000463) |
| 13 |
89000464
|
#13 LH sticker grey/white (#89000464) |
| 14 |
31945467
|
#32 Fuse table decal (#31945467) |
| 15 |
31460588
|
#15 Two-seat saddle Nevada Club (#31460588) |
| 16 |
89000470
|
#16 RH sticker red/grey (#89000470) |
| 16 |
89000471
|
#16 RH sticker blue/grey (#89000471) |
| 16 |
89000472
|
#16 RH sticker grey/white (#89000472) |
| 17 |
89000460
|
#17 LH sticker grey/white (#89000460) |
| 17 |
89000461
|
#17 LH stic.beige/grey (#89000461) |
| 18 |
89000468
|
#18 RH sticker grey/black (#89000468) |
| 18 |
89000469
|
#18 RH sticker beige/grey (#89000469) |
| 19 |
31923380
|
#19 Decal set (#31923380) |
| 19 |
31923381
|
#19 Decal set (#31923381) |
| 19 |
31923382
|
#19 Decal set (#31923382) |
| 19 |
31923383
|
#19 Decal set (#31923383) |
| 19 |
31923384
|
#19 Decal set (#31923384) |
| 20 |
95005306
|
WASHER (#95005306) |
| 21 |
98084312
|
BOLT, rear drive snap ring (#98084312) |
