2002 California Special Sport al. PL 1100 Crankshaft Piston
| Position | Part Number | Description |
|---|---|---|
| 1 | 03060130 | CYL&PIST ASSY EACH SIDE (#03060130) |
| 1 | 03060132 | RH/LH Cylinder Piston Kit (#03060132) |
| 2 | 98084420 | BOLT (#98084420) |
| 3 | 03060230 | PISTON ASSEMBLY EACH (#03060230) |
| 4 | 30060660 | PISTON RING SET #30060660) (#30060660) |
| 5 | 30060760 | PISTON RING TOP (#30060760) |
| 6 | 30060960 | PISTON RING 2ND (#30060960) |
| 7 | 30061060 | PISTON RING 3RD (#30061060) |
| 8 | 30061241 | WRIST PIN (#30061241) |
| 9 | 90351038 | CIRCLIP (#90351038) |
| 10 | 14020865 | BASE GASKET (#14020865) |
| 11 | 90706094 | O RING-VITON (#90706094) |
| 12 | 12021800 | BOLT (#12021800) |
| 13 | 12021700 | BOLT-ROD (#12021700) |
| 14 | 01061532 | Connecting Rod (#01061532) |
| 15 | 01062230 | Bolt, Conrod (#01062230) |
| 16 | 91112128 | BUSH-CON ROD (#91112128) |
| 17 | 01062030 | Bearing, Half (#01062030) |
| 17 | 01062031 | Bearing half-shell min.0,254 (#01062031) |
| 17 | 01062032 | Bearing half-shell min.0,508 (#01062032) |
| 17 | 01062033 | Bearing half-shell min.0,762 (#01062033) |
| 18 | 37064106 | CRANKSHAFT D (#37064106) |
| 19 | 37065405 | CRANK PLUG (#37065405) |
| 20 | 03067030 | FLYWHEEL D (#03067030) |
| 21 | 12067701 | SCREW (#12067701) use 597150 |
| 22 | 14615901 | WASHER (#14615901) |
| 23 | 17067900 | RING GEAR (#17067900) |
| 24 | 19025300 | VIBR. DAMPER PI (#19025300) |
