2002 California Special Sport al. PL 1100 Frame Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 98622430 | SCREW (#98622430) |
| 2 | 3500660 | #02 Ubolt (#3500660) |
| 3 | 98052560 | BOLT (#98052560) |
| 4 | 3500260 | #04 Lower Ubolt (#3500260) |
| 5 | 27530505 | WASHER (#27530505) USE AP8123511 |
| 6 | 27530503 | RUBBER SLEEVE A (#27530503) |
| 7 | 3493100 | #07 Fork upper plate (#3493100) |
| 8 | 3498100 | #08 Ring nut (#3498100) |
| 9 | 3530503 | #25 Spacer (#3530503) |
| 10 | 92630110 | NUT (#92630110) |
| 11 | 3494000 | #11 Stem base (#3494000) |
| 12 | 3530548 | #12 Plug cpl. (#3530548) |
| 13 | 3530541 | #13 Oring (#3530541) |
| 14 | 3530549 | #14 Rod (#3530549) |
| 15 | 3530550 | #15 Ring (#3530550) |
| 16 | 3530551 | #12 Drift (#3530551) |
| 17 | 3530552 | #17 Preload tube (#3530552) |
| 18 | 3526600 | #18 Spring (#3526600) |
| 19 | 3525440 | #19 Sleeve (#3525440) |
| 20 | 3530510 | #20 Lower bush (#3530510) |
| 21 | ||
| 22 | 3530524 | #22 Dust cover (#3530524) |
| 23 | 3530525 | #23 Stop ring (#3530525) |
| 24 | 3530526 | FORK SEAL (#3530526) |
| 25 | 3530527 | #25 Cup (#3530527) |
| 26 | 3530528 | #26 Upper bush (#3530528) |
| 27 | 3490730 | #27 LH hub cpl. (#3490730) |
| 28 | 3522601001 | #28 LH sleeve (#3522601001) |
| 29 | 3490630 | #29 RH hub cpl. (#3490630) |
| 30 | 3522501001 | #30 RH sleeve (#3522501001) |
| 31 | 98680340 | Screw (#98680340) |
| 32 | 3530529 | #02 Washer (#3530529) |
| 33 | 3530530 | #01 Screw M10x30 (#3530530) |
| 34 | 3530521 | #34 Stroke limit stop (#3530521) |
| 35 | 98370619 | BOLT (#98370619) |
| 36 | 1517700 | #21 Decal Aquilia (#1517700) |
| 37 | 95005307 | Washer (#95005307) |
| 38 | 23943410 | CHROME PLUG (#23943410) |
