2002 California Special Sport al. PL 1100 Rear Wheel
| Position | Part Number | Description |
|---|---|---|
| 1 | 03630650 | REAR WHEEL (#03630650) |
| 2 | 14615901 | WASHER (#14615901) |
| 3 | 92204220 | BEARING (#92204220) |
| 4 | 14634051 | SPACER (#14634051) |
| 5 | 30631160 | SPOKE SHORT (#30631160) |
| 6 | 12616101 | BALANCE WEIGHT (#12616101) |
| 6 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 6 | 12616103 | BALANCE WEIGHT (#12616103) |
| 7 | 30631430 | SPOKE, LONG (#30631430) |
| 8 | 03611740 | SPOKE NIPPLE (#03611740) |
| 9 | 03635701 | BRAKE ROTOR (#03635701) |
| 10 | 30611460 | ALLEN BOLT (#30611460) |
| 11 | 03633350 | AXLE - REAR (#03633350) |
| 12 | 01336800 | RUBBER BLOCK (#01336800) |
| 13 | 90706490 | O RING (#90706490) |
| 14 | 30335260 | DISC-CUSH DRIVE B (#30335260) |
| 15 | 14335303 | RING (#14335303) |
| 16 | 17335950 | LOCK PLATE (#17335950) |
| 17 | 03013800 | WAVE WASHER (#03013800) |
| 18 | 98084312 | BOLT, rear drive snap ring (#98084312) |
| 19 | 03634150 | REAR AXLE SPACER (#03634150) |
| 20 | 95008219 | Washer (#95008219) |
| 21 | 92630718 | AXLE NUT (#92630718) |
| 22 | 03632440 | FLANGE A (#03632440) |
| 23 | 90272047 | CIRCLIP (#90272047) |
| 24 | 17633550 | CUP (#17633550) |
| 25 | 98822430 | BOLT (#98822430) |
| 26 | 03630740 | REAR RIM D (#03630740) |
| 27 | 90271055 | CIRCLIP (#90271055) |
