2002 California Special Sport al. PL 1100 Transmission Complete I
| Position | Part Number | Description |
|---|---|---|
| 1 | 03540250 | REAR FORK (#03540250) |
| 2 | 98460105 | Threaded Dowel (m5x6) (#98460105) |
| 3 | 90706584 | O RING (#90706584) |
| 4 | 03547800 | NUT (#03547800) |
| 5 | 12547200 | SPACER (#12547200) |
| 6 | 30547060 | PIVOT PIN A (#30547060) |
| 7 | 90403040 | SEAL, REAR FORK SPINDLE (#90403040) |
| 8 | 92249217 | BEARING (#92249217) |
| 9 | 18548000 | U JOINT BOOT (#18548000) |
| 10 | 93306050 | Clamp (#93306050) |
| 11 | 93306070 | Clamp (#93306070) |
| 12 | 03328050 | UJOINT CAL SERIES POST 2002 (#03328050) |
| 13 | 90271020 | CIRCLIP (#90271020) |
| 14 | 92204230 | BEARING (#92204230) |
| 15 | 12327700 | SLEEVE (#12327700) |
| 16 | 93180105 | PLUG (#93180105) |
