2003 2005 California EV PL Cat. 1100 Dashboard
| Position | Part Number | Description |
|---|---|---|
| 1 | 03761570 | SPEEDOMETER,KMH BLACK FACE (#03761570) |
| 1 | 03762470 | SPEEDO EV , TITANIUM, ALUMINIUMM BLACK FACE (#03762470) |
| 2 | 03760074 | Dashboard complete (#03760074) |
| 2 | 03760075 | EV II, COMPLETE DASH (#03760075) |
| 3 | 91551168 | Button Seal (#91551168) |
| 4 | 03760465 | SPEEDO CABLE 50 1/2 OVERALL LENGTH (#03760465) |
| 5 | 03762550 | SPEEDO DRIVE ASSY (#03762550) |
| 6 | 01782500 | IGNITION SWITCH (#01782500) |
| 7 | 02768600 | LAMP HOLDER (#02768600) |
| 8 | 93450120 | BULB ALL GLASS (#93450120) |
| 9 | 03767270 | Tachometer, Black face (#03767270) |
| 10 | 03762370 | Gasket (#03762370) |
| 11 | 98872110 | ALLEN BOLT (#98872110) |
| 12 | 02764000 | BRACKET (#02764000) |
| 13 | 02762301 | SPEEDO/TAC RUBBER GASKET (#02762301) |
| 14 | 03762070 | Speedometer Box (#03762070) |
| 15 | 03761970 | Tachometer Box (#03761970) |
| 16 | 95008208 | WASHER (#95008208) |
| 17 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 18 | 01766031 | Socket Support (#01766031) |
| 19 | 93222023 | Silent - Block (#93222023) |
| 20 | 93400012 | Lamp Holder End (#93400012) |
| 21 | 98370609 | BOLT (#98370609) |
| 22 | 03747270 | Dashboard cable (#03747270) |
| 23 | 92660007 | NUT(#92660007) |
| 24 | 98692318 | ALLEN SCREW (#98692318) |
| 25 | 95008306 | WASHER (#95008306) |
| 26 | 31766283 | Dash Lamp Cover (#31766283) |
| 27 | 98872120 | ALLEN BOLT (#98872120) |
| 28 | 02768200 | GSKT (#02768200) |
| 29 | 02768400 | PROTECTION-DASH (#02768400) |
| 30 | 03781150 | LENS (#03781150) |
| 31 | ||
| 32 | 03766570 | Lower Cover (#03766570) |
| 33 | 97260415 | SECURITY BOLT A (#97260415) |
| 34 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 35 | 95021206 | Washer (#95021206) |
| 36 | 03762870 | TRIP RESET KNOB (#03762870) |
