2003 2005 California EV PL Cat. 1100 Driven Shaft
| Position | Part Number | Description |
|---|---|---|
| 1 | 14213612 | SHAFT (#14213612) |
| 2 | 14217410 | LOCK NUT (#14217410) |
| 3 | 43083810 | ADJUSTING WASHER (#43083810) |
| 4 | 14215400 | WASHER (#14215400) |
| 5 | 03215100 | GEAR 4TH A (#03215100) |
| 6 | 92259017 | RACE (#92259017) |
| 7 | 92251022 | CAGE-BUSHING (#92251022) |
| 8 | 30231025 | SLEEVE 3-4 B (#30231025) |
| 9 | 14232512 | SLEEVE (#14232512) |
| 10 | 14218011 | WASHER (#14218011) |
| 11 | 03214800 | GEAR 3RD (#03214800) |
| 12 | 14213001 | BUSH (#14213001) |
| 13 | 03214500 | GEAR 2ND A (#03214500) |
| 14 | ||
| 15 | 92295702 | BALL (#92295702) |
| 16 | 14217300 | SHIM (#14217300) |
| 17 | 14215213 | GEAR (#14215213) |
| 18 | 30214225 | GEAR 1ST B (#30214225) |
| 19 | 30230725 | SLEEVE 1-2 B (#30230725) |
| 20 | 03234400 | SHIFT DRUM (#03234400) |
| 21 | 14235500 | WASHER (#14235500) |
| 22 | 55235000 | SHIM 0.6MM (#55235000) |
| 22 | 55235001 | SHIM 0.8MM (#55235001) |
| 22 | 55235002 | SHIM 1.0MM (#55235002) |
| 22 | 55235003 | SHIM 1.2MM (#55235003) |
| 23 | 14234300 | ROD (#14234300) |
| 24 | 14234600 | PIN (#14234600) |
| 25 | 14232400 | ROD (#14232400) |
| 26 | 14230501 | SLIDING FORK (#14230501) |
| 27 | 14231201 | SHIFT FORK (#14231201) |
| 28 | 90706219 | O RING (#90706219) |
| 29 | 28217350 | WASHER (#28217350) |
| 30 | 92251030 | CAGE (#92251030) |
| 31 | 90706203 | O RING (#90706203) |
| 32 | 03236250 | PRESELECTOR (#03236250) |
| 33 | 28238261 | SHIFT RETURN SPRING (#28238261) |
