2003 2009 Breva ie 750 Frame Front Body Duct
| Position | Part Number | Description |
|---|---|---|
| - | ||
| - | 32576210 | RH Air Intake, Blank - Breva (#32576210) |
| - | 32576211 | RH Air Vent Dark Grey - Breva (#32576211) |
| - | 32576212 | RH lat.fairing, grey cr. (#32576212) |
| - | 32576213 | RH Air Intake, Silver - Breva (#32576213) |
| - | 32576214 | RH lat.fairing, grey pl. (#32576214) |
| - | 32576215 | PRESA ARIA DX TECHNOGREY (#32576215) |
| - | 32576281 | PRESA ARIA DX BIANCO (#32576281) |
| - | 32576310 | LH Air Vent Black - Breva (#32576310) |
| - | 32576311 | LH Air Vent Dark Grey - Breva (#32576311) |
| - | 32576312 | LH lat.fairing, grey cr. (#32576312) |
| - | 32576313 | LH Air Vent Silver - Breva (#32576313) |
| - | 32576314 | LH lat.fairing, grey pl. (#32576314) |
| - | 32576315 | LH lat.fairing technogrey (#32576315) |
| - | 32576381 | PRESA ARIA SX BIANCO (#32576381) |
| - | 32576610 | RH Bumper - Breva (#32576610) |
| - | 977313 | RH fairing - red (#977313) |
| - | 977314 | LH lat.fairing, red (#977314) |
| - | 977316 | LH lat.fairing, black (#977316) |
| - | 977326 | LH protection grey (#977326) |
| - | 977459 | RH lateral fairing, sky blue (#977459) |
| - | 977460 | LH lateral fairing, sky blue (#977460) |
| - | 977539 | RH SIDE PANEL BREVA 750 - WHITE (#977539) |
| - | 977540 | LH SIDE PANEL BREVA 750 - WHITE (#977540) |
| - | ||
| 1 | 977325 | RH protection grey (#977325) |
| 2 | 977315 | RH fairing black (#977315) |
| 3 | ||
| 4 | ||
| 5 | 32576710 | LH Bumper - Breva (#32576710) |
| 6 | ||
| 7 | 32476410 | Water Cooler Grille - Breva (#32476410) |
| 8 |
