2003 2009 Breva ie 750 Saddle Central Bod

Position Part Number Description
1 32579110 RH protection blank (#32579110)
1 325791100C LH protection black (#325791100C)
1 32579111 RH Protection - Breva (#32579111)
1 32579180 Cover (#32579180)
1 977311 RH protection black (#977311)
1 977323 RH protection red (#977323)
1 977465 RH protection cyan (#977465)
1 977545 Cover (#977545)
2 32476210 RH Body Panel Blank - Breva (#32476210)
2 32476210Y05 RH side panel (#32476210Y05)
2 32476211 RH Side Panel Grey - Breva (#32476211)
2 32476212 RH side panel technogrey (#32476212)
2 32476213 RH Side Panel Grey - Breva (#32476213)
2 32476281 RH side panel (#32476281)
2 977317 RH side panel, red (#977317)
2 977319 RH side panel, black (#977319)
2 977463 RH Side panel cyan (#977463)
2 977543 RH side panel, White (#977543)
3 AP8150450 Washer for Shafts (#AP8150450)
4 32460510 Saddle Black/Grey (#32460510)
4 32460511 Saddle Red - Breva (#32460511)
4 32460580 SADDLE (#32460580)
5 32476310 LH body panel blank (#32476310)
5 32476310Y05 FIANCHETTO COPRIBAT SX GRIGO LUCE BREVA (#32476310Y05)
5 32476311 LH Side Panel, Chr. Grey (#32476311)
5 32476312 LH side panel technogrey (#32476312)
5 32476313 LH Side Panel Plat. Grey - Bre (#32476313)
5 32476381 LH side panel (#32476381)
5 977318 LH side panel, red (#977318)
5 977320 LH side panel, black (#977320)
5 977464 BODY PANEL (#977464)
5 977544 LH side panel (#977544)
6 32579210 LH protection blank (#32579210)
6 325792100C RH protection black (#325792100C)
6 32579211 LH Protection - Breva (#32579211)
6 32579280 Cover (#32579280)
6 977321 LH protection black (#977321)
6 977324 LH protection red (#977324)
6 977466 LH protection cyan (#977466)
6 977546 Cover (#977546)
7 02573900 GROMMET (#02573900)
8 AP8120030 Rubber Spacer (#AP8120030)
9 AP8152339 SCREW W/FLANGE (#AP8152339)
10 AP8102375 Clip (#AP8102375)
11 AP8126702 Saddle rubber (#AP8126702)
12 AP8144087 Front lateral rubber (#AP8144087)
13 AP8220349 Saddle rubber (#AP8220349)
