2004 2008 Nevada Classic ie 750 Frame Rear Electrical System
| Position | Part Number | Description |
|---|---|---|
| - | 14609650 | TIE WRAP (#14609650) |
| - | 28742560 | FUSE 15A (#28742560) use 290860 |
| - | 977308 | ECU (#977308) |
| 1 | 32747160 | Main Wiring Harness - Nevada (#32747160) |
| 2 | 32747910 | Ground Lead - Breva (#32747910) |
| 3 | 32729510 | ECU - Breva (#32729510) |
| 4 | ||
| 5 | ||
| 6 | ||
| 7 | ||
| 8 | ||
| 9 | ||
| 10 | ||
| 11 | 49609601 | TIE STRAP (#49609601) |
| 12 | ||
| 13 | 32418210 | Clamp - Breva (#32418210) |
| 14 | ||
| 15 | 32748010 | Wiring - Breva (#32748010) |
| 16 | 30729330 | AIR TEMP SENSOR (#30729330) |
| 17 | 30027931 | GASKET (#30027931) |
| 18 | ||
| 19 | ||
| 20 | ||
| 21 | ||
| 22 | 28742562 | FUSE 30A (#28742562) |
| 23 | ||
| 24 | 98682215 | Hex Socket Screw M5X15 (#98682215) |
| 25 | 95100059 | WASHER (#95100059) |
| 26 | ||
| 27 | 31112965 | PLATE (#31112965) |
| 28 | 32517710 | Decal (#32517710) |
| 29 | 95129101 | WASHER FUEL PUMP (#95129101) |
