2008 2010 1200 Sport 8v 1200 Headlight Horn
| Position | Part Number | Description |
|---|---|---|
| 1 | 05740530 | Headlight (#05740530) |
| 1 | 05740531 | Cpl Headlightsteering Headligh (#05740531) |
| 2 | AP8127109 | Lamp H7-12V-55W (#AP8127109 ) USE 294353 |
| 3 | 93450265 | LAMP H9-12V-65W (#93450265) |
| 4 | 93450105 | PARKING LIGHT BULB (#93450105) USE 292022 |
| 5 | 98692318 | ALLEN SCREW (#98692318) |
| 6 | 05578630 | Rh Support (#05578630) |
| 7 | 98682435 | Hex Socket Screw (#98682435) |
| 8 | 05578631 | Lh Support (#05578631) |
| 9 | ||
| 10 | ||
| 11 | AP8127552 | Turn indicator lens (#AP8127552) |
| 12 | 93450126 | BULB- T/SIG. (#93450126) USE 584332 |
| 13 | 92630206 | NUT (#92630206) |
| 14 | 05743730 | Horn (#05743730) |
| 15 | AP8152286 | SCREW W/FLANGE (#AP8152286) |
| 16 | 95100244 | WASHER (#95100244) |
| 18 | AP8152300 | Self-Locking Nut (#AP8152300) |
| 19 | AP8144707 | Gasket (#AP8144707) |
| 20 | 978158 | Bush (#978158) |
| 21 | 978157 | Screw (#978157) |
| 22 | 98710215 | SCREW (#98710215) |
