2008 Stelvio 1200 1200 Front Body Front Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 978418 | Cowling (unpainted) (#978418) |
| 1 | 97841800Y11 | WINDSHIELD (#97841800Y11) |
| 2 | 978423 | WINDSHIELD (#978423) |
| 3 | 98257618 | Screw, (#98257618) |
| 4 | 269787 | WINDSHIELD WASHER (#269787) |
| 5 | 560173 | Grommet for upper windscreen (#560173) |
| 6 | 977583 | LH support (#977583) |
| 7 | 977584 | RH support (#977584) |
| 8 | 977600 | Special screw (#977600) |
| 9 | 95005310 | WASHER (#95005310) |
| 10 | 14615901 | WASHER (#14615901) |
| 11 | 977681 | STELVIO WINDSHIELD KNOB (#977681) |
| 12 | 977596 | RH clamp (#977596) |
| 13 | 977597 | LH clamp (#977597) |
| 14 | AP8152278 | #12 Screw w/ flange M6x16* (#AP8152278 ) |
| 15 | 977698 | BUSSOLA A T 8,2X10,2X11,6COL 20X2,5 (#977698) |
| 16 | 92640708 | DADO IX NY M8X8,3 BASSO (#92640708) |
| 17 | 978170 | RUBBER CUP (#978170) |
| 18 | ||
| 19 | 977699 | SPACER (#977699) |
| 20 | 883069 | COMPLETE CAPPING (#883069) |
| 21 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 22 | 463195 | Buffer for fairing fitting (#463195) |
| 23 | AP8102375 | Clip (#AP8102375) |
| 24 | AP8102381 | CLIP M4 (#AP8102381) |
| 25 | AP8120876 | Plug (#AP8120876) |
