2008 Stelvio 1200 1200 Lubrication
| Position | Part Number | Description |
|---|---|---|
| 1 | 978895 | OIL RADIATOR DELIVERY OIL PIPE (#978895) |
| 2 | 01154230 | GASKET (#01154230) |
| 3 | 874223 | SCREW FOR PIPE FITTING (#874223) |
| 4 | 874669 | Nipple (#874669) |
| 5 | 976592 | GASKET (#976592) |
| 6 | 434947 | RING (#434947) |
| 7 | 874646 | PIPE (#874646) |
| 8 | 13763 | #08 Washer (#13763) |
| 9 | 874645 | INTAKE PIPE (#874645) |
| 10 | 969323 | O RING (#969323) |
| 11 | 874655 | INTAKE OIL FILTER (#874655) |
| 12 | 621914 | SCREW (#621914) |
| 13 | 01161331 | REDUCER (#01161331) |
| 14 | 978896 | PIPE (#978896) |
| 15 | 874240 | COMPLETE OIL NOZZLE LEFT CYLINDER (#874240) |
| 16 | 978854 | MINIMUM PRESSURE OIL SWITCH (#978854) USE 1D001138 |
| 17 | 874239 | COMPLETE OIL NOZZLE RIGHT CYLINDER (#874239) |
| 18 | 874238 | Circlip (#874238) |
| 19 | 976597 | GASKET (#976597) |
| 20 | 976625 | HEAD CYLINDER DELIVERY OIL PIPE (#976625) |
| 21 | 981114 | #21 O-ring (#981114) |
