2008 Stelvio 1200 1200 Rear Body I
| Position | Part Number | Description |
|---|---|---|
| 1 | 978446 | MUDGUARD FLAP (#978446) |
| 2 | AP8102375 | Clip (#AP8102375) |
| 3 | AP8152339 | SCREW W/FLANGE (#AP8152339) |
| 4 | 883024 | RH side panel, unpainted (#883024) |
| 5 | 883023 | LH side panel, unpainted (#883023) |
| 6 | 97863800Y10 | BAG SUPPORT RIGHT SIDE (#97863800Y10) |
| 7 | 97863900Y10 | BAG SUPPORT LEFT SIDE (#97863900Y10) |
| 8 | 883100 | Battery holder (#883100) |
| 9 | 06418600 | PIASTRA FERMO BATTERIA (#06418600) |
| 10 | AP8150377 | BUTTON HEAD SCREW (#AP8150377) |
| 11 | 06704700 | RACCORDO A 2 VIE D2,5 OTTONE (#06704700) |
| 12 | AP8220263 | Breather Pipe (#AP8220263) |
| 13 | AP8152280 | Screw (#AP8152280) |
| 13 | AP8152287 | Screw w/flange (#AP8152287) |
| 14 | 01576530 | Nut with Clip (#01576530) |
| 14 | 28576591 | CLIP (#28576591) |
| 15 | AP8120708 | Black adh.cable guid (#AP8120708) |
| 16 | 98710215 | SCREW (#98710215) |
| 17 | 883177 | BOCCOLA 6.2X10X10.7 COL 13X1.5 (#883177) |
