2009 2010 Stelvio 1200 NTX ABS 1200 Connecting Rod Rear Shock Abs
| Position | Part Number | Description |
|---|---|---|
| 1 | 978006 | REAR ABSORBER (#978006) |
| 2 | AP8152398 | Screw w/ flange M10x (#AP8152398) |
| 3 | 05560330 | Double Conrod (#05560330) |
| 4 | AP8135924 | Double connecting ro (#AP8135924) |
| 5 | AP8110066 | Needle bearing (#AP8110066) |
| 6 | AP8110068 | Oil seal D18x24x3 (#AP8110068) |
| 7 | 05562030 | Double Connecting Rod Pin L47 (#05562030) |
| 8 | AP8135608 | Double connecting rod pin (#AP8135608) |
| 9 | AP8152397 | Hex socket screw m10 (#AP8152397) |
| 10 | AP8121155 | T bush * (#AP8121155) |
| 11 | AP8152301 | Self-locking nut M10 (#AP8152301) |
| 12 | AP8152147 | Hex screw M10x47 (#AP8152147) |
| 13 | AP8150292 | Curved Spring Washer (#AP8150292) |
| 14 | 05562430 | Single Conrod (#05562430) |
| 15 | AP8152482 | Screw w/ flange M10 X 85 (#AP8152482) |
| 16 | AP8152396 | Hex screw M10x95 (#AP8152396) |
