2009 2010 Stelvio 1200 NTX ABS 1200 Frame Front Wheel
| Position | Part Number | Description |
|---|---|---|
| - | 5681430 | #16 Wheel speed sensor, left front (#5681430) |
| - | 883009 | FRONT WHEEL (#883009) |
| - | 896011 | RH front brake disc (#896011) |
| - | 978764 | BRAKE DISC (#978764) |
| - | 978810 | Nipple (#978810) |
| - | 978814 | VALVE (#978814) |
| - | ||
| 1 | 883385 | RIGHT BRAKE CALIPER RADIAL LINK (#883385) |
| 3 | ||
| 4 | ||
| 5 | 978516 | Spacer (#978516) |
| 6 | 978864 | Spoke (#978864) |
| 7 | 883287 | NIPPLES (#883287) |
| 8 | 896012 | LH front brake disc (#896012) USE B044280 |
| 9 | ||
| 10 | 978030 | Pin (#978030) |
| 11 | 1612190 | #11 Nut (#1612190) |
| 12 | 14616150 | WEIGHTS (#14616150) |
| 13 | ||
| 14 | ||
| 15 | 978811 | Ring (#978811) |
| 16 | 90706061 | O RING (#90706061) |
| 17 | 883372 | Brake whit disc (#883372) |
| 18 | ||
| 19 | 98250510 | SCREW (#98250510) |
| 20 | 859792 | Sensor ABS (#859792) |
| 21 | 598839 | SCREW (#598839) |
| 22 | 49609601 | TIE STRAP (#49609601) |
| 23 | 859777 | Plate (#859777) |
| 24 | ||
| 25 | ||
| 28 | 894704 | Fairlead (#894704) |
