2009 2010 Stelvio 1200 NTX ABS 1200 Frame Handlebar Controls
| Position | Part Number | Description |
|---|---|---|
| - | 859810 | LH lights selector (#859810) USE 896108 |
| - | 883544 | RH Device ABS (#883544) |
| - | 886234 | TAG (TERMINAL) (#886234) |
| - | 978558 | RH lights selector (#978558) |
| - | ||
| 1 | 978040 | Handlebar (#978040) |
| 2 | 978821 | Holder (#978821) |
| 3 | 98700430 | BOLT FOR UPPER U BOLT GRISO 850/1100 (#98700430) |
| 4 | 978042 | RISER (#978042) |
| 5 | ||
| 6 | 896108 | LH lights selector (#896108) |
| 7 | ||
| 8 | ||
| 9 | 98680340 | Screw (#98680340) |
| 10 | ||
| 11 | 886159 | RH ELETTRICAL DEVICE (#886159) |
| 12 | 1603480 | #14 RH hand grip (#1603480) |
| 13 | ||
| 14 | ||
| 15 | 883001 | STARTER CABLE (#883001) |
| 16 | 883002 | Throttle cable (#883002) |
| 17 | 1609630 | #11 Hose clamp L46 mm (#1609630) |
| 18 | 978059 | SCREW (#978059) |
| 19 | 883460 | RH rearview mirror (#883460) |
| 20 | 883461 | LH rearview mirror (#883461) |
| 21 | 981101 | FRONT INDICATORS (#981101) |
| 22 | 981099 | FRONT INDICATORS LENS(#981099) |
| 23 | 981100 | FRONT INDICATORS (#981100) |
| 24 | 884312 | MIRROR MOUNTING STUD (# 884312) (#884312) |
