2009 2010 Stelvio 1200 NTX ABS 1200 Rear Handle Luggage Rack
| Position | Part Number | Description |
|---|---|---|
| 1 | 97843900Y10 | handle support (#97843900Y10) |
| 2 | AP8152280 | Screw (#AP8152280) |
| 3 | 98682416 | Hex Socket Screw (#98682416) USE 319165 |
| 4 | 14615901 | WASHER (#14615901) |
| 5 | 05466630 | RH LUGGAGE RACK SUPPORT (#05466630) |
| 6 | 05466631 | LH LUGGAGE RACK SUPPORT (#05466631) |
| 7 | 98230820 | ALLEN BOLT A (#98230820) |
| 8 | 98350430 | Hex Socket Screw (#98350430) |
| 9 | AP8152154 | Washer 8,4x13* (#AP8152154) |
| 10 | AP8121890 | Rear stand bush (#AP8121890) |
| 11 | 98250635 | SCREW (#98250635) |
| 12 | 883047 | Cover (#883047) |
| 13 | AP8150509 | Self-taping screw (#AP8150509) |
| 14 | 03013800 | WAVE WASHER (#03013800) |
| 15 | AP8102375 | Clip (#AP8102375) |
| 16 | 98710215 | SCREW (#98710215) |
