2009 V7 Cafe 750 Frame Front Fork II
| Position | Part Number | Description |
|---|---|---|
| - | 01530568 | WASHER (#01530568) USE 599504 |
| - | ||
| - | 03530530 | ALLEN BOLT (#03530530) |
| - | 03530551 | PLUG (#03530551) |
| - | 27530584 | FORK SEAL V1100 SPORT,750 BREVA,LM (#27530584) |
| - | 30525861 | BUSHING LOWER #30525861) (#30525861) |
| - | 31504583 | Plug Complete (#31504583) |
| - | 32504210 | Sleeve Protection - Breva (#32504210) |
| - | 32525410 | FORK TUBE (#32525410) |
| - | 32526610 | Spring (#32526610) |
| - | 32530501 | STOP RING (#32530501) |
| - | 32530502 | Return Spring - Breva (#32530502) |
| - | 32530503 | Rod - Breva (#32530503) |
| - | 599502 | dust cover for fork tube (#599502) |
| - | 887882 | BUSHING (887882) (#887882) |
| - | 887893 | Pipe (#887893) |
| - | 887899 | Washer (#887899) |
| - | 887900 | NUT (#887900) |
| - | 887905 | Ring (#887905) |
| - | 887916 | SEAL RING (O-RING) (#887916) |
| - | 978974 | Stem Base - Breva (#978974) |
| - | 98620540 | SCREW (#98620540) |
| - | 98680330 | Screw (#98680330) |
| 1 | 887878 | SPECIAL SCREW (#887878) |
| 2 | 887879 | Washer (#887879) |
| 3 | 887880 | SCREW (CYLINDER HEAD) (#887880) |
| 4 | 978978 | Lh Sleeve Complete - (#978978) |
| 5 | 30526761 | BUSHING UPPER A (#30526761) |
| 6 | 887883 | Washer (#887883) |
| 7 | 887884 | Gasket ring (#887884) |
| 8 | 887885 | Stop ring (#887885) |
| 9 | 887886 | Dust cover (#887886) |
| 10 | 887887 | Sleeve (#887887) |
| 11 | 887888 | BUSHING (887888) (#887888) |
| 12 | 887889 | Drift (#887889) |
| 13 | 887890 | Return spring (#887890) |
| 14 | 887891 | Plunger, complete (#887891) |
| 15 | 887892 | Spring (#887892) |
| 16 | 32526310 | Pipe (#32526310) |
| 17 | 887894 | Plug cpl. (#887894) |
| 18 | 887895 | SCREW (CYLINDER HEAD) (#887895) |
| 19 | 887896 | Stem base (#887896) |
| 20 | 31513480 | BOLT M25X1 (#31513480) |
| 21 | 978976 | Fork Upper Plate - Breva (#978976) |
| 22 | 32530505 | O-ring (#32530505) |
| 23 | 883498 | BUSHING (#883498) |
| 24 | 883552 | BUSHING (#883552) |
| 25 | 27530510 | WASHER (#27530510) |
| 26 | 95005330 | Washer (#95005330) |
| 27 | 92630106 | NUT USE 92630707 (#92630106) |
| 28 | 32530504 | Ring - Breva (#32530504) |
| 29 | 978977 | Rh Sleeve Complete (#978977) |
| 30 | 98680350 | Hex socket screw (#98680350) |
| 31 | 23943410 | CHROME PLUG (#23943410) |
| 32 | 32530610 | FORK SEAL AND DUST COVER KIT (#32530610) |
| 33 | 32530611 | Fork Seal Kit (#32530611) |
| 34 | 887917 | Sleeve protection (#887917) |
| 35 | 883602 | PROTECTION (#883602) |
| 36 | 887906 | RH sleeve (#887906) |
| 37 | 887881 | LH sleeve (#887881) |
