2010 2013 Norge 1200 ie 8v Frame Central Body
| Position | Part Number | Description |
|---|---|---|
| - | 883518 | RH side panel (#883518) |
| - | ||
| - | ||
| - | ||
| - | ||
| - | ||
| - | 883889 | HALF PILLAR (#883889) |
| - | ||
| - | ||
| - | 883890 | HALF PILLAR (#883890) |
| - | ||
| - | ||
| - | 883977 | LH rear panel (#883977) |
| - | 884278 | RH rear panel P.A. (#884278) |
| 1 | ||
| 2 | 883891 | CARRIER BATTERY (#883891) |
| 3 | ||
| 4 | ||
| 5 | ||
| 6 | ||
| 7 | ||
| 8 | ||
| 9 | 898051 | SPACER (#898051) |
| 10 | ||
| 11 | ||
| 12 | 883519 | LH side panel (#883519) |
| 13 | 977619 | RH support (#977619) |
| 14 | 977623 | LH SUPPORT (#977623) |
| 15 | 884277 | LH rear panel P.A. (#884277) |
| 16 | 883978 | RH rear panel (#883978) |
| 17 | ||
| 18 | 883520 | RH COVER (#883520) |
| 19 | 883521 | LH COVER (#883521) |
| 20 | 883946 | FRAME FRONT SIDE (#883946) |
| 21 | 883947 | FRAME FRONT SIDE (#883947) |
| 22 | 31576183 | Spacer (#31576183) |
| 24 | 91180506 | Spacer 5,2X7X6,3 (#91180506) |
| 25 | ||
| 26 | 883630 | COVERING (#883630) |
| 27 | 883629 | COVERING FOR COVER HEAD (#883629) |
| 28 | 898254 | Plate (#898254) |
| 29 |
