2010 2013 Norge 1200 ie 8v Frame Electrical System I
| Position | Part Number | Description |
|---|---|---|
| - | 01722701 | SENSOR GSKT .4MM (#01722701) |
| - | 01722702 | SENSOR GSKT .6MM (#01722702) |
| - | 01722703 | SENSOR GSKT .8MM (#01722703) |
| - | 01722704 | SESOR GSKT 1.MM (#01722704) |
| - | 01722705 | SENSOR GSKT 1.5MM (#01722705) |
| - | 14609650 | TIE WRAP (#14609650) |
| - | 29722760 | SENSOR GASKET (#29722760) |
| 1 | 886209 | Main wiring harness (#886209) |
| 2 | 883820 | Electronic control unit (#883820) |
| 3 | 05729230 | Bushing (#05729230) |
| 4 | ||
| 5 | ||
| 6 | ||
| 7 | ||
| 8 | 30716500 | IGNITION COIL (#30716500) |
| 9 | 05716730 | Coil Holder (#05716730) |
| 10 | 98682125 | Screw (#98682125) |
| 11 | 95008204 | Washer (#95008204) |
| 12 | 92630104 | NUT (#92630104) |
| 13 | 642243 | H.T. CABLE (#642243) |
| 14 | 642221 | Spark plug cap (#642221) |
| 15 | 639687 | SPARK PLUG CR8EKB (NGK) (#639687) |
| 16 | 01721600 | TIMING SENSOR (#01721600) |
| 17 | 847180 | O-RING (#847180) |
| 18 | 01722700 | Gasket (#01722700) |
| 19 | 98682212 | Hex Socket Screw (#98682212) |
| 20 | 95008205 | Washer 5.3mm (#95008205) |
| 21 | 29729461 | OIL TEMP SENSOR (#29729461) |
| 22 | 976556 | Support (#976556) |
| 23 | 98683520 | SCREW (#98683520) |
| 24 | 30609600 | FASTENER A (#30609600) |
| 25 | ||
| 26 | ||
| 27 | 883799 | CABLE HARNESS (#883799) |
| 28 | 01731760 | RELAY 5 PIN (#01731760) |
| 30 | 886776 | CABLE HARNESS (#886776) |
