2011 2013 Stelvio 1200 8v Std NTX Blow By System
| Position | Part Number | Description |
|---|---|---|
| 1 | 886098 | TANK BOW-BY (#886098) |
| 2 | 06412300 | PIASTRINA FISSAGGIO BLOWBY (#06412300) |
| 3 | AP8120030 | Rubber Spacer (#AP8120030) |
| 4 | 598839 | SCREW (#598839) |
| 5 | 883034 | PIPE (#883034) |
| 6 | 883035 | PIPE (#883035) |
| 7 | AP8102349 | WHITE HOSE CLIP D17,5x8 (#AP8102349) |
| 8 | 883036 | Pipe (#883036) |
| 9 | 01161331 | REDUCER (#01161331) |
| 10 | 01154230 | GASKET (#01154230) |
| 11 | AP8102765 | Hose Clamp (#AP8102765) |
| 12 | 00823955080 | MOLLA (#00823955080) |
| 13 | AP8220162 | Rubber spacer (#AP8220162) |
| 14 | AP8102764 | HOSE COUPLING D13 (#AP8102764) |
| 15 | AP8101586 | Hose clip d.15,5x6,6 (#AP8101586) |
| 16 | 28576591 | CLIP (#28576591) |
| 17 | 886339 | 2-way union (#886339) |
