2011 2013 Stelvio 1200 8v Std NTX Engine Clutch
| Position | Part Number | Description |
|---|---|---|
| - | 976594 | CLUTCH DRIVE SYSTEM ROD (#976594) |
| - | 976595 | CLUTCH DRIVE SYSTEM ROD (#976595) |
| - | 976596 | CLUTCH DRIVE SYSTEM ROD (#976596) |
| - | ||
| - | ||
| 1 | 976695 | Clutch cpl. (#976695) |
| 2 | 976053 | ASSY DRIVEN PLATE (#976053) USE B064100 |
| 3 | 978739 | CLUTCH OIL PUMP (#978739) |
| 4 | 598839 | SCREW (#598839) |
| 5 | 976535 | SCREW (#976535) |
| 6 | 98230612 | ALLEN SCREW (#98230612) |
| 7 | 976481 | SCREW TE FL DA (#976481) |
| 8 | 976484 | Axle Washer (#976484) |
| 9 | ||
| 10 | 976564 | BUSH (#976564) |
| 11 | 14085900 | CLUTCH PUSH ROD SEAL (TAKES 2) (#14085900) |
| 12 | 976593 | CLUTCH DRIVE SYSTEM ROD (#976593) |
| 13 | 14086000 | INNER CLUTCH BODY (#14086000) |
| 14 | 976696 | KIT CUSCINETTO REGGISPINTA (#976696) |
