2011 2013 Stelvio 1200 8v Std NTX Front Footrests
| Position | Part Number | Description |
|---|---|---|
| 1 | 886987 | RH foot rest support (#886987) |
| 2 | 883103 | LEFT FOOTREST BRACKET ASSY (#883103) |
| 3 | 886184 | RH Foot rests (#886184) |
| 4 | AP8120831 | Footrest Rubber (#AP8120831) |
| 5 | AP8134276 | PIASTRINA INT.GOMMA PEDANA PIL (#AP8134276) |
| 6 | AP8221277 | FOOT PEG SPRING (#AP8221277) |
| 7 | AP8152277 | Screw w/flange (#AP8152277) |
| 8 | AP8121567 | Pin (#AP8121567) |
| 9 | AP8152409 | STOP RING (#AP8152409) |
| 10 | 886185 | LH Foot rests (#886185) |
| 12 | 98680435 | Screw (#98680435) |
| 13 | AP8152300 | Self-Locking Nut (#AP8152300) |
| 14 | 14615901 | WASHER (#14615901) |
| 15 | 98680480 | Screw, 8mmx80mm (#98680480) |
| 16 | 98682425 | Screw M8 X 25 (#98682425) |
| 17 | 98680465 | SCREW (#98680465) |
| 18 | 98680460 | Hex socket screw M8x60 (#98680460) |
| 19 | 98620485 | BOLT (#98620485) |
| 20 | 883107 | Spacer (#883107) |
| 21 | 886933 | Spacer (#886933) |
