2011 2013 Stelvio 1200 8v Std NTX Front Wheel I
| Position | Part Number | Description |
|---|---|---|
| 1 | 883009 | FRONT WHEEL (#883009) |
| 1 | 884093 | Front wheel (#884093) |
| 1 | 884168 | Front wheel (#884168) |
| 2 | AP8125777 | Bearing 6005-2rs1 (#AP8125777) |
| 3 | AP8125773 | Gasket ring 30x47x7 (#AP8125773) |
| 4 | 978516 | Spacer (#978516) |
| 5 | 887085 | Front spoke (#887085) |
| 5 | 978864 | Spoke (#978864) |
| 6 | 978810 | Nipple (#978810) |
| 7 | AP8101744 | Tubeless tyre valve (#AP8101744) |
| 8 | 978811 | Ring (#978811) |
| 9 | 90706061 | O RING (#90706061) |
| 10 | 894704 | Fairlead (#894704) |
| 11 | 896012 | LH front brake disc (#896012) USE B044280 |
| 12 | 896011 | RH front brake disc (#896011) |
| 13 | AP8128189 | encoder (#AP8128189) |
| 14 | AP8152286 | SCREW W/FLANGE (#AP8152286) |
| 15 | 978030 | Pin (#978030) |
| 16 | 01612190 | Nut, Front Axle (#01612190) USE AP8152335 |
| 17 | 06616300 | SPACER (#06616300) |
| 18 | 14616150 | WEIGHTS (#14616150) |
| 19 | 859792 | Sensor ABS (#859792) |
| 20 | AP8152273 | Screw w/flange (#AP8152273) |
| 21 | 859777 | Plate (#859777) |
| 22 | AP8201749 | Screw M4x6 (#AP8201749) |
| 23 | 49609601 | TIE STRAP (#49609601) |
| 24 | 886311 | TYRE (#886311) |
