2011 V7 Racer 750 Generator Regulator
| Position | Part Number | Description |
|---|---|---|
| 1 | 883877 | ALTERNATOR (#883877) |
| 2 | 883878 | Regulator (#883878) |
| 3 | 30714201 | WASHER (#30714201) |
| 4 | 92606516 | Nut (#92606516) |
| 5 | 29711460 | FRONT COVER (#29711460) |
| 6 | 98680265 | Screw (#98680265) |
| 7 | 29217960 | WASHER (#29217960) |
| 8 | 19007700 | RUBBER (#19007700) |
| 9 | 31712365 | Spacer (#31712365) |
| 10 | 91600450 | WOODRUFF KEY (#91600450) |
| 11 | 29711960 | REAR COVER (#29711960) |
| 12 | AP8152281 | Screw w/ flange M6x30* (#AP8152281) |
| 13 | 28576591 | CLIP (#28576591) |
| 14 | 95100125 | WASHER (#95100125) |
