2012 2013 V7 Special Stone 750 Crankshaft Cpl
| Position | Part Number | Description |
|---|---|---|
| 1 | 320642104 | Drive shaft (#320642104) |
| 2 | 19065400 | PLUG (#19065400) |
| 3 | 27061585 | CON ROD ASSY B (#27061585) |
| 4 | 19062261 | CON ROD BOLT (#19062261) |
| 5 | 14615901 | WASHER (#14615901) |
| 6 | 27062060 | BEARING (#27062060) |
| 7 | 27065660 | BEARING (#27065660) |
| 8 | 27066560 | RR MAIN BEARING 1/2 (#27066560) |
| 9 | 27066460 | THRUST WASH (#27066460) |
| 10 | 8872690001 | CYLINDER-PISTON GROUP (#8872690001) |
| 10 | 8872690002 | CYLINDER-PISTON GROUP (#8872690002) |
| 10 | 8872690003 | CYLINDER-PISTON GROUP (#8872690003) |
| 11 | B063018 | Slot piston ring (#B063018) |
| 12 | B063020 | Scraper ring (#B063020) |
| 13 | B063016 | PISTON PIN (#B063016) |
| 14 | 874567 | Circlip (#874567) |
| 15 | B063019 | Slot piston ring (#B063019) |
| 16 | B063466 | PISTON RING KIT (#B063466) |
| 17 | 27061885 | CON ROD BUSHING A (#27061885) |
| 18 | 19067700 | SCREW (#19067700) |
| 19 | B063465 | CYLINDER-PISTON-PIN-RING (#B063465) |
| 20 | 61027200 | O RING (#61027200) |
| 21 | 886670 | GASKET (#886670) |
