2012 2013 V7 Special Stone 750 Frame Front Fork II
| Position | Part Number | Description |
|---|---|---|
| - | ||
| - | 3530551 | #12 Drift (#3530551) |
| - | 27530506 | NUT (#27530506) |
| - | 27530510 | WASHER (#27530510) |
| - | 27530584 | FORK SEAL V1100 SPORT,750 BREVA,LM (#27530584) |
| - | 30512830 | NUT (#30512830) |
| - | 30525861 | BUSHING LOWER #30525861) (#30525861) |
| - | 30526761 | BUSHING UPPER A (#30526761) |
| - | 32504210 | Sleeve Protection - Breva (#32504210) |
| - | 32526310 | Pipe (#32526310) |
| - | 32526610 | Spring (#32526610) |
| - | 32530501 | STOP RING (#32530501) |
| - | 32530503 | Rod - Breva (#32530503) |
| - | 32530504 | Ring - Breva (#32530504) |
| - | 32530505 | O-ring (#32530505) |
| - | 887878 | SPECIAL SCREW (#887878) |
| - | 887879 | Washer (#887879) |
| - | 887886 | Dust cover (#887886) |
| - | 887887 | Sleeve (#887887) |
| - | 887890 | Return spring (#887890) |
| - | 887894 | Plug cpl. (#887894) |
| - | 887895 | SCREW (CYLINDER HEAD) (#887895) |
| - | 887898 | Fork upper plate (#887898) |
| - | 887901 | Rubber spacer (#887901) |
| - | 887902 | Spacer (#887902) |
| - | 887903 | Cup (#887903) |
| - | 887912 | Lower U-bolt (#887912) |
| - | 887913 | Upper U-bolt (#887913) |
| - | 887914 | Screw (#887914) |
| - | 887918 | Washer (#887918) |
| - | 978974 | Stem Base - Breva (#978974) |
| - | 98052560 | BOLT (#98052560) |
| - | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 1 | 3530530 | #01 Screw M10x30 (#3530530) |
| 2 | 3530529 | #02 Washer (#3530529) |
| 3 | 887880 | SCREW (CYLINDER HEAD) (#887880) |
| 4 | 978978 | Lh Sleeve Complete - (#978978) |
| 5 | 887882 | BUSHING (887882) (#887882) |
| 6 | 887883 | Washer (#887883) |
| 7 | 887884 | Gasket ring (#887884) |
| 8 | 887885 | Stop ring (#887885) |
| 9 | 1530571 | #09 Dust cover (#1530571) |
| 10 | 32525410 | FORK TUBE (#32525410) |
| 11 | 887888 | BUSHING (887888) (#887888) |
| 12 | 887889 | Drift (#887889) |
| 13 | 32530502 | Return Spring - Breva (#32530502) |
| 14 | 887891 | Plunger, complete (#887891) |
| 15 | 887892 | Spring (#887892) |
| 16 | 887893 | Pipe (#887893) |
| 17 | 31504583 | Plug Complete (#31504583) |
| 18 | 98620540 | SCREW (#98620540) |
| 19 | 887896 | Stem base (#887896) |
| 20 | 31513480 | BOLT M25X1 (#31513480) |
| 21 | 978976 | Fork Upper Plate - Breva (#978976) |
| 22 | 887899 | Washer (#887899) |
| 23 | 887900 | NUT (#887900) |
| 24 | 32530506 | Rubber spacer (#32530506) |
| 25 | 91181039 | Spacer (#91181039) |
| 26 | 27530505 | WASHER (#27530505) USE AP8123511 |
| 27 | 887904 | Nut (#887904) |
| 28 | 887905 | Ring (#887905) |
| 29 | 978977 | Rh Sleeve Complete (#978977) |
| 30 | 978972 | Lower U-bolt (#978972) |
| 31 | 978973 | Upper U-bolt (#978973) |
| 32 | 66530505 | ALLEN BOLT (#66530505) USE 98682430 |
| 33 | 887915 | Screw (#887915) |
| 34 | 887916 | SEAL RING (O-RING) (#887916) |
| 35 | 887917 | Sleeve protection (#887917) |
| 36 | 23943410 | CHROME PLUG (#23943410) |
| 37 | 32530610 | FORK SEAL AND DUST COVER KIT (#32530610) |
| 38 | 32530611 | Fork Seal Kit (#32530611) |
| 39 | 887906 | RH sleeve (#887906) |
| 40 | 887881 | LH sleeve (#887881) |
