2012 Nevada S Anniversario 750 Frame Rear Body I Mudguard
| Position | Part Number | Description |
|---|---|---|
| - | 978946 | REAR FENDER (#978946) |
| 1 | ||
| 2 | 978947 | REAR COVER (#978947) |
| 3 | ||
| 4 | 254485 | SPRING PLATE (M6) (#254485) |
| 5 | 98690435 | Hex socket screw (#98690435) |
| 6 | 91120806 | SPACER (#91120806) |
| 7 | 95005310 | WASHER (#95005310) |
| 8 | 92630108 | NUT 8MM (#92630108) |
| 9 | ||
| 10 | 91180601 | Spacer (#91180601) |
| 11 | ||
| 12 | ||
| 13 | ||
| 14 |
