2012 V7 Racer 750 Frame Exhaust Unit
| Position | Part Number | Description |
|---|---|---|
| - | 887846 | EXHAUST PIPE CYLINDER (#887846) |
| - | 887847 | EXHAUST PIPE CYLINDER (#887847) |
| 1 | ||
| 2 | ||
| 3 | ||
| 4 | 978387 | FASCETTA SERR SILENZ SX D 45 (#978387) |
| 5 | 19025280 | GASKET, EXHAUST (#19025280) |
| 6 | 19025460 | Spacer (#19025460) |
| 7 | 32121010 | Ring Nut - Breva (#32121010) |
| 8 | 03013800 | WAVE WASHER (#03013800) |
| 9 | 31121880 | Exhaust flange nut (#31121880) |
| 10 | 8837125 | LH silencer (#8837125) |
| 11 | 8837115 | RH silencer (#8837115) |
| 12 | 978385 | Hose clamp (#978385) |
| 13 | 32128610 | RH Plate - Breva (#32128610) |
| 14 | 32129010 | LH Plate - Breva (#32129010) |
| 15 | 978386 | Clamp (#978386) |
| 16 | ||
| 17 | 98680440 | Screw (#98680440) |
| 18 | ||
| 19 | 92640508 | Nut (#92640508) |
| 20 | ||
| 21 | 896110 | Lamda sensor (#896110) |
| 22 | ||
| 23 | 98110007 | PLUG (#98110007) |
| 24 | 30109330 | COPPER WASHER (#30109330) |
| 25 | 32121910 | Silencer Protection - Breva (#32121910) |
| 26 | 32121911 | LH Protection - Breva (#32121911) |
| 27 | 98370609 | BOLT (#98370609) |
| 28 | 95005306 | WASHER (#95005306) |
| 29 | 91113826 | Bushing (#91113826) |
| 30 |
