1972 1974 850 Eldorado Ignition And Lighting
| Position | Part Number | Description |
|---|---|---|
| 10 | 12700205 | GENERATOR (#12700205) |
| 11 | 12700300 | GENERATOR BRACKET (#12700300) |
| 12 | 98054420 | BOLT (#98054420) |
| 13 | 95021108 | WASHER (#95021108) |
| 14 | 12700700 | BAND (#12700700) |
| 15 | 95716280 | PIN (#95716280) |
| 16 | 95716380 | PIN (#95716380) |
| 17 | 99105127 | BOLT (#99105127) |
| 18 | 12700900 | PIN (#12700900) |
| 19 | 95500222 | SPLIT PIN (#95500222) |
| 20 | 12700610 | COVER, GEN NLA (#12700610) |
| 21 | 12702505 | GEN BELT BOSCH (#12702505) |
| 22 | 98054312 | BOLT (#98054312) |
| 23 | 95021106 | WASHER, WAVE (#95021106) |
| 24 | 12715701 | BRACKET (#12715701) |
| 25 | 12715901 | GASKET (#12715901) |
| 26 | 98054425 | BOLT (#98054425) |
| 27 | 95101231 | FLAT WASHER (#95101231) |
| 28 | 12715400 | ***DIST***N/A (#12715400) |
| 29 | ||
| 30 | 95510318 | PIN (#95510318) |
| 31 | 98106021 | BOLT (98106021) (#98106021) |
| 32 | 95100137 | WASHER (#95100137) |
| 33 | 26716504 | IGNITION COIL W/BRACKET (#26716504) USE 40611 |
| 34 | 98054412 | BOLT (#98054412) |
| 35 | 9260 2208 | Nut, regulator to bracket and coil and horn securing screws (#9260 2208) |
| 36 | ||
| 37 | 12717600 | Cap (#12717600) |
| 38 | 45717600 | CAP (#45717600) |
| 39 | ||
| 40 | 45717450 | CAP (#45717450) |
| 41 | 12718501 | 13718660 (#12718501) |
| 42 | 55717000 | SPARK PLUG (#55717000) |
| 43 | 12719305 | H.T. LEAD (#12719305) |
| 44 | ||
| 45 | 12730705 | USE 30730711 VALEO STARTER BOSH SYSTEM ONLY (#12730705) |
| 45 | 12731000 | GROUND CBL (#12731000) |
| 46 | 12703805 | REGULATOR BOSCH OEM (#12703805) USE 040005 |
| 46 | 12747700 | WIRE (#12747700) |
| 47 | 12732800 | BRACKET (#12732800) |
| 48 | 12732705 | CABLE (#12732705) |
| 49 | 12704200 | ***GSKT**N/A (#12704200) |
| 50 | ||
| 51 | 12735750 | IG SWITCH COVER (#12735750) |
| 52 | 90706252 | O RING (#90706252) |
| 53 | 12735400 | LOCK RING (#12735400) |
| 54 | 12735500 | KEY E SERIES (#12735500) |
| 55 | 26735001 | PUSH BUTTON (26735001) (#26735001) |
| 56 | 90706163 | O RING (#90706163) |
| 57 | 12734900 | SUPPORT PLATE *USED ONLY* (#12734900) |
| 58 | 25707100 | CAP-STARTER (#25707100) |
| 59 | 92602206 | NUT (#92602206) USE STHN6MM |
| 60 | 95100130 | WASHER (#95100130) |
| 61 | ||
| 62 | 98054214 | BOLT (#98054214) |
| 63 | 95000205 | WASHER (#95000205) |
| 64 | 95021105 | LOCK WASHER (#95021105) |
| 65 | 92602205 | NUT (#92602205) |
| 66 | 12732605 | CBL HARNESS (#12732605) |
| 67 | 98054320 | BOLT (#98054320) |
| 68 | 95100121 | WASHER (#95100121) |
| 70 | 91551053 | GROMMET (#91551053) |
| 70 | 93301175 | CABLE CLAMP (#93301175) |
