1974 1975 850 T Cylinder Heads
| Position | Part Number | Description |
|---|---|---|
| 1 | 14023502 | COVER R H (#14023502) |
| 2 | 14023602 | COVER LEFT V7 SPORT & T (#14023602) |
| 3 | 12023700 | V/C GASKET (#12023700) |
| 4 | 98620330 | V/COVER BOLT (#98620330) USE 98680330 |
| 5 | 14022101 | CYL HEAD RH (#14022101) |
| 6 | 14022201 | CYL HEAD (#14022201) |
| 7 | 13036800 | VALVE GUIDE (#13036800) USE 13036801A |
| 8 | 13036900 | VALVE GUIDE (#13036900) USE 13036801 |
| 9 | 90353016 | VALVE GUIDE CLIP (#90353016) |
| 10 | 14022001 | HEAD GASKET -(14022001) supercedes to 14022050 (#14022001) |
| 11 | 13060162 | C CYL 850 T/T3 (#13060162) |
| 12 | 13020800 | BASE GASKET (#13020800) USE 14020850 |
| 13 | 90706090 | O RING (#90706090) USE 90706094 |
| 14 | 12022600 | PLUG (#12022600) |
| 15 | 90706203 | O RING (#90706203) |
| 16 | ||
| 17 | 95129180 | WAVE WASHER (#95129180) |
| 18 | 12021800 | BOLT (#12021800) |
| 19 | 12021700 | BOLT-ROD (#12021700) |
| 20 | 14018400 | WASHER (#14018400) |
| 21 | 92751103 | NUT (#92751103) |
| 22 | 14115500 | CARB MANIFOLD GASKET (#14115500) |
| 23 | 14115902 | Right Manifold (#14115902) |
| 24 | 14115003 | INTAKE MANIFOLD (#14115003) |
| 25 | 98346010 | SCREW CHROME (#98346010) |
| 26 | 95100116 | WASHER (#95100116) |
| 27 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 28 | 90716083 | WASHER (#90716083) |
| 29 | 95004208 | WASHER (#95004208) |
| 30 | 14115400 | WIRE GUIDE (#14115400) USE 14115401 |
| 31 | 91551081 | GROMMET (#91551081) |
| 32 | 96508042 | STUD USE 96508040 (#96508042) |
