1974 1975 850 T Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 17400100 | FRAME (#17400100) |
| 1 | 17400101 | Frame (#17400101) |
| 1 | 17400120 | FRAME BARE (#17400120) |
| 2 | 93180080 | PLUG (#93180080) |
| 3 | 98054425 | BOLT (#98054425) |
| 4 | 95000208 | WASHER (#95000208) |
| 5 | 91180810 | SPACER (#91180810) |
| 6 | 14103400 | TANK BUSHING (#14103400) |
| 7 | 14107100 | RUBBER BUSHING (#14107100) |
| 8 | 14109000 | BUSHING (#14109000) |
| 9 | 14420301 | RH ARM (#14420301) |
| 10 | 14422101 | LH ARM (#14422101) |
| 11 | 14423800 | RUBBER (#14423800) |
| 12 | 98623635 | SCREW USE 9881 3635 (#98623635) |
| 13 | 98621670 | SCREW (#98621670) |
| 14 | 95021112 | WASHER (#95021112) |
| 15 | 92602312 | NUT (#92602312) |
| 16 | 14429505 | BOLT (#14429505) |
| 17 | 95000213 | WASHER (#95000213) |
| 19 | 14429600 | BOLT (#14429600) |
| 20 | 14429800 | SPACER (#14429800) |
| 21 | 14429900 | SPACER (#14429900) |
| 22 | 14424500 | SUPPORT (#14424500) |
| 23 | 14430302 | CENTER STAND USE 17430345 (#14430302) |
| 24 | 14432900 | PLATE USE 03432970 RH (#14432900) |
| 25 | 14433200 | PLATE USE 0343 3270 LH (#14433200) |
| 26 | 12434001 | SPRING (#12434001) |
| 27 | 14433500 | BUSHING (#14433500) |
| 28 | 98052545 | SCREW (#98052545) |
| 29 | 95004210 | WASHER (#95004210) |
| 30 | 14433400 | WASHER (#14433400) |
| 31 | 95021110 | WASHER (#95021110) |
| 32 | 92602210 | NUT (#92602210) |
| 33 | 14432001 | SIDE STAND T SERIES (#14432001) |
| 34 | 99105129 | BOLT (#99105129) |
| 35 | 14434000 | SPRING (#14434000) |
| 36 | 17450200 | Crash Bar (17450200) use 17450300 OR 17450400 (#17450200) |
| 37 | 17450300 | SAFETY BAR RH (#17450300) |
| 38 | 17450400 | SAFETY BAR LH (#17450400) |
| 39 | 98054420 | BOLT (#98054420) |
| 40 | 95004208 | WASHER (#95004208) |
| 41 | 95021108 | WASHER (#95021108) |
| 42 | 92602208 | NUT (#92602208) |
| 43 | 14418200 | BATTERY PLATE (#14418200) |
| 44 | 98054416 | BOLT (#98054416) |
| 45 | 14477200 | SQUARE PLATE (#14477200) |
| 46 | 14447200 | PLATE RH (#14447200) |
| 47 | 14447300 | PLATE LH (#14447300) |
| 48 | 17443600 | FOOTPEG RH (#17443600) |
| 49 | ||
| 50 | 14443200 | FOOT PEG RUBBER (#14443200) |
| 51 | 13442360 | FOOT REST (#13442360) |
| 52 | 55443385 | PEDAL PAD RUBBER (#55443385) |
| 53 | 98052325 | BOLT (#98052325) |
| 54 | 92602206 | NUT (#92602206) USE STHN6MM |
| 55 | ||
| 55 | 17918400 | Plate (#17918400) |
| 56 | 45918570 | RIVET (#45918570) |
